Help CenterJack Crane Car Lifting Hydraulic Cylinder
Related Products
-
Clevis Rod Ends Tie-rod Small Double Acting Hydraulic Cylinder for Agricultural MachineryUS$ 30 - 100MOQ: 20 Pieces -
Hydraulic Ram Farm Use Agricultural Hydraulic Cylinder PriceUS$ 18 - 100MOQ: 10 Pieces
-
Double Acting Tie Rod Hydraulic Cylinder Used for Agricultural EquipmentUS$ 5 - 100MOQ: 10 Pieces
-
Compact Tie Rod Hydraulic Cylinder for Agricultural EquipmentUS$ 20 - 100MOQ: 1 Piece
-
Agricultural Tie Rod Hydraulic Cylinder for AgriculturalUS$ 25 - 200MOQ: 10 Pieces
Description:
Tie rod hydraulic cylinders, or simply tie rod cylinders are designed with threaded steel rods to fix the two end caps to the cylinder barrel, and the steel rod are always durable and feature high strength.tie rod hydraulic cylinders are commonly used in industrial factories.
Tie rod cylinders with small bore are usually designed with tie rods, while large bore hydraulic cylinders usually need more, such as 16 or 20 tie rods. One of the outstanding advantages of the tie rod hydraulic cylinder is that they can be completely disassembled. This assists in cylinder repair and maintenance.
The dimension of tie rod style hydraulic cylinders is standardized by the National Fluid Power Association.Hence, cylinders from different manufacturers are interchangeable within the same mountings.
Technical data of tie rod hydraulic cylinders:
2T Series: 2500 PSI Working Pressure 4000 PSI Proof Pressure
3T Series: 3000 PSI Working Pressure 6000 PSI Proof Pressure
Materials for making 2T 3T Series Agricultural Tie Rod Hydraulic Cylinders
tie rod hydraulic cylinder Materials:
Gland--high grade ductile iron
Tube--cold draw honed tubing
Tube seal--O-Ring with anti-exthusion backup washer
TIE rod--high tensile steel
Piston rod - chrome plated C45 steel
Rod clevis --ductile iron
End caps --high grade ductile iron
Piston ---high grade ductile iron ,precision machined
Piston wear ring( for 3T Series only)--glass filled nylon wear ring
Rod wiper--metal encased nitrile rubber
Rod seal--urethane
Ports--NPTF for 2T , SAE ORB 3T
Paint colour--seni-gloss black, or other customized colors
we also customize cylinder for our customer.
Please provide us your request or drawings.
About us:
Founded in 1986, our skilled craftsmen, using the newest methods and technologies, allow us to produce the durable, high quality, hydraulic cylinders that today's industrial world demands. We offer a solid product, competitive prices, on-time deliveries, quick order to ship times and we stand behind our product before and after the sale. Whether a single, custom cylinder or a mass order, we can deliver hydraulic cylinders of the highest quality, the first time!
The products and services offered by us include a total design service coupled with full system testing. As an ISO certified (ISO 9001-2008) company, we are confident of meeting the quality requirements of our valued customers.
tie rod hydraulic cylinder Drawing:
Tie Rod Hydraulic Cylinder pictures:
Our factory:
