Specifications
Hydraulic cylinder1.30 year's manufacture experience
2. ISO 9001:2008 Certificate
3.One year warranty
Agricultural Hydraulic cylinder steel hydraulic cylinder
Specifications:
Working Pressure: 2500PSI (21MPa) ~ 4000PSI (28MPa).
Working Temperature: -20oC ~ 100oC.
Size for hydraulic cylinder for sale,small hydraulic cylinder,telescopic hydraulic cylinder:
Bore Size -- 2" ~ 10"
Stroke-------- 2" ~ 300"
Rod size-----1"~10"
General material for hydraulic cylinder for sale,small hydraulic cylinder,telescopic hydraulic cylinder:
Gland----High grade ductile iron
Tube-----Cold drawn honed tubing
Tube seal---O-ring with anti-exthusion backup washer
Tir rod------High tensile steel
Piston rod----Chrome plated C1045 steel
Rod clevis----Ductile iron
End caps-----High grade ductile iron
Piston--------High grade ductile iron,precision machined
Piston wear ring---Glass filled nylon wear ring
Rod wiper----Metal encased nitrile rubber
Rod seal------Urethane
Oil port-------2TNPT,3TSAE
Paint color----Semi-gloss black,or other customized colors
hydraulic cylinder drawing:
Our factory for hydraulic cylinder for sale,small hydraulic cylinder,telescopic hydraulic cylinder:
1) We are a professional hydraulic cylinder manufacturer in Tie Rod hydraulic cylinders,welded hydraulic cylinders,plunger type hydraulic cylinders and OEM hydraulic cylinders.they are used for construction machinery,mining, forestry, marine, demolition, military, material handling, agricultural machinery,farm equipment, truck and trailer, loader, utility and waste management.
2)With countless hours of testing, you can be assured that our products have long life, superior performance and high reliability.
Our processing machines for hydraulic cylinder for sale,small hydraulic cylinder,telescopic hydraulic cylinder:
Our products:
Our sample room for hydraulic cylinder for sale,small hydraulic cylinder,telescopic hydraulic cylinder:
Passed ISO 9001:2008 certificate
