top3 brand wonray tires solid trailer tire 3.60-8 with wheel rims for sale

Name: top3 brand wonray tires solid trailer tire 3.60-8 with wheel rims for sale
Brand: WonRay, WRST
Price: USD $20 - 200 / Piece

FOB Price

USD $20 - $200 / Piece

1 Piece(Min.Order)

Supply Ability 4000 Piece / Pieces per Month
Port Qingdao
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

Shandong, China

Brand Name:

WonRay, WRST

Model Number:

3.60-8

Packaging Details

nude, container, as requested

Product Description

top3 brand wonray tires solid trailer tire 3.60-8 with wheel rims for sale

1, special tires for trailers, solid rubber tire, Yantai WonRay, WRST

2, low rolling resistence, strong puncture-free capacity, high loading capacity, suitable for the tow vehicles in airports, seaports, station etc.

3, size: 3.60-8, Rim size: 3.00D.

specifications & technical parameters:

size of tire	3.60-8
rim size	3.00D
outside diameter (±5mm)	360
static radius under load (mm)	170
section width (±5mm)	100
approx net weight (±1.5%kg)	9.0

Featured photos show:

All sizes available


	size of tire	rim size	outside diameter (mm)	static radius under load (mm)	section width (mm)	approx net weight (kg)	Max load(kg) counter balanced lift trucks						other industrial vehicles (kg)
			±5mm	mm	±5mm	±1.5%kg	10km/h		16km/h		25km/h		16km/h
			±5mm	mm	±5mm	±1.5%kg	driving	steering	driving	steering	driving	steering	16km/h
1	2.00-8	3.00D	312	152	100	6.0	550	440	530	400	495	370	380
2	3.20-8	3.00D	320	147	100	7.0	735	570	695	530	630	480	520
3	3.60-8	3.00D	360	170	100	9.0	870	660	820	625	740	560	600
4	4.00-8	3.00D	400	198	108	12.0	1055	845	1020	765	950	715	730
5	16×5-9	3.50	408	190	126	12.0	1650	1255	1605	1220	1535	1170	1230
6	300×125		300		125								910
7	350×100		350		100								850
8	266×160		266		160								1190
9	400×133		400		133								1570
10	430×100		430		100								1080

Wonray series chooses new tread pattern,strictly controll production cost and truly achieve low price with high quality.

1,Three compound construction, a new design popular in Europe and America

2,Wear resistant tread compound

3,Resilient center compound

4,Super base compound

5,Steel ring reinforced

WRST series is newly developed as our featured product which can be used on different kinds of poor working environment.

♦,Extremely deep tread pattern and unique tread design are two factors which provide WRST series higher wear resistance than other similar brand.

♦,Big tread pattern design increase tire contact, reduce ground pressure, lower rolling resistance, strenghthen wear resistance.

Quality standard:

TRA in USA, ETRTO in Europe, JATMA in Japan, ISO9001:2008

Aplication:

Our solid tire is suitable for trailers, loaders, forklifts, lifting platform, and various industrial vehicles for mining, construction, railway, steel plant, seaport, airport, clean factory,etc.

Products: Pneumatic solid tyre, solid tyres for forklifts and small field running vehicles, Special tires for trailers, Non-Marking Tire, Solid OTR Tires, Solid Tires with Rims, Skid Steer Solid Tires, Solid Tires with holes,Tire for lifting platform, Press-on solid tires, Rims

More sizes is available. For more information, please contact with us at any time.

Call: 86 15853521337 Ms. Sunny Zhang

Skype: sunnyzhang

high quality, excellent performance & reasonable price!

Company Profile

Yantai Wonray Rubber Tire Co., Ltd.

Yantai Wonray Rubber Tire Co., Ltd. is a comprehensive enterprise engaged in researching, producing and selling industrial tires with high performance at low costs. Our annual production capacity is 300,000 pieces, among which 40% products are exported to oversea markets like North America, Europe, Southeast Asia, Oceania, Africa, etc. Our sales network spreads all over China, and we can provide excellent and complete after-sales services for all customers.

We master advanced processing technology by closely cooperating with European Tires Technology Research Center. Now we have 2 production bases in Shanghai, advanced test equipment, qualified raw materials and professional members to control production technology. These are the potential advantage for us to ensure our product quality to reach the leading position in the world.

All our products meet the standards TRA in the USA, ETRTO in Europe and JATMA in Japan.

We could provide you with the best solutions and help you choose tires suitable for vehicles working in different environment such as seaport, logistics base, mine, aviation, clean factory, and so on.

We welcome your enquiries.
