Fast Delivery Low Speed Loader Tyres14.00-24 From China
fast delivery low speed loader tyres14.00-24 from China
1, high loading, low rolling resistence, lower energy consumption, higher wear and anti-puncture resistence, no exploading, lower cost of maintenance
such kind of tire is widely used on the special vehicle of port, mine metallurgical industry.
2, eight sizes
Featured photos show:
Specifications & technical parameter
| size of tire | rim size | outside diameter (mm) |
static radius under load (mm) |
section width (mm) |
approx net weight (kg) |
Max load(kg) counter balanced lift trucks | other industrial vehicles (kg) |
||||||
| ±5mm | mm | ±5mm | ±1.5%kg | 10km/h | 16km/h | 25km/h | 16km/h | ||||||
| driving | steering | driving | steering | driving | steering | ||||||||
| 1 | 9.00-16 | 5.50, 6.00, 60.50 | 860 | 416 | 216 | 102.0 | 5300 | 4240 | 5220 | 3915 | 5100 | 3870 | 3950 |
| 2 | 9.00-20 | 6.50T, 7.00, 7.50 | 960 | 470 | 242 | 130.0 | 5900 | 4675 | 5780 | 4335 | 5380 | 4035 | 4130 |
| 3 | 10.00-20 | 7.50, 8.00 | 1030 | 510 | 258 | 166.0 | 7200 | 5400 | 6950 | 5215 | 6620 | 4965 | 5215 |
| 4 | 11.00-20 | 8.00 | 1120 | 520 | 280 | 220.0 | 8440 | 6750 | 8160 | 6110 | 7610 | 5680 | 5840 |
| 5 | 12.00-20 | 8.00, 8.50, 10.00 | 1120 | 535 | 280 | 222.0 | 8455 | 6755 | 8165 | 6125 | 7600 | 5700 | 5830 |
| 6 | 12.00-24 | 8.50, 10.00 | 1208 | 591 | 302 | 298.0 | 9575 | 7655 | 9235 | 6925 | 8600 | 6450 | 6595 |
| 7 | 14.00-20 | 10.00 | 1250 | 590 | 316 | 341.5 | 10800 | 8640 | 10430 | 7840 | 9730 | 7315 | 7450 |
| 8 | 14.00-24 | 10.00 | 1380 | 636 | 328 | 393.0 | 12760 | 10210 | 12320 | 9240 | 11460 | 8595 | 8800 |
Quality standard:
TRA in USA, ETRTO in Europe, JATMA in Japan, ISO9001:2008
Aplication:
Our solid tire is suitable for trailers, loaders, forklifts, lifting platform, and various industrial vehicles for mining, construction, railway, steel plant, seaport, airport, clean factory,etc.
Products: Pneumatic solid tyre, solid tyres for forklifts and small field running vehicles, Special tires for trailers, Non-Marking Tire, Solid OTR Tires, Solid Tires with Rims, Skid Steer Solid Tires, Solid Tires with holes,Tire for lifting platform, Press-on solid tires, Rims

More sizes is available. For more information, please contact with us at any time.
Call: 86 15853521337 Ms. Sunny Zhang
Skype: sunnyzhang
high quality, excellent performance & reasonable price!
