15x5 Scissor Lift Solid Tyre, Wheel Assembled
Our solid tyre in different sizes fits for many kind of aerial scissor lift platform such as Genie, JLG, Skyjack, Snorkel, UpRight, MEC, Condor, Grove, Haulotte, Aichi, etc
Each size we have with brake and without brake type.
Product description
Wonray series chooses new tread pattern,strictly controll production cost and truly achieve low price with high quality.
1,Three compound construction, a new design popular in Europe and America
2,Wear resistant tread compound
3,Resilient center compound
4,Super base compound
5,Steel ring reinforced
| Our Brand | WonRay,WRST | |||||
| our advantages | 1,OEM,manufacturer | |||||
| 2,natural rubber,stable quality | ||||||
| 3,good ride | ||||||
| 4,no slipping ring and delamination problem | ||||||
| 5,long wear,no exploding,long life | ||||||
| 6,thick rubber,high loading capacity | ||||||
| 7,energy saving | ||||||
| 8,for different environment and temperature | ||||||
| quality standard | TRA,JATMA,ETRTO | |||||
| main market | Europe,America,Japan | |||||
No. | Size of Tire | Rim Size | Outside Diameter | Section Width | Net Weight(Kg) | Max Load (Kg) |
Other Industrial Vehicles | ||||||
| ±5mm | ±5mm | ±1.5%kg | 10km/h | |||
| 1 | 10*4 (with RIM) | FB | 256.00 | 101.60 | 5.90 | 630 |
| 2 | 12*4 (with brake) | FB | 310.00 | 100.00 | 8.60 | 680 |
| 3 | 12*4 (W/O brake) | FB | 310.00 | 100.00 | 8.30 | 680 |
| 4 | 15x5 | FB | 381.00 | 127.00 | 9.60 | 995 |
| 5 | 16*5*12(with brake) | FB | 406.00 | 125.00 | 17.40 | 1265 |
| 6 | 16*5*12(W/O brake) | FB | 406.00 | 125.00 | 16.20 | 1265 |
| 7 | 2.00-8(12*4) | 2.50C/3.00 | 310.00 | 100.00 | 5.00 | 620 |
Packaging & Shipping
| package | nude or pallet | |||||
| delevery time | 15-20 days | |||||
| payment | 30% by TT in advance | |||||
| min order | 0 | |||||
| shipment port | Qingdao | |||||
| production capacity | 3000 pieces/month | |||||
Our services:
| product group | forklift solid tyre | |||||
| skid steer solid tyre | ||||||
| industrial OTR solid tyre | ||||||
| trailer solid tyre | ||||||
| lift platform solid tyre | ||||||
| non marking solid tyre | ||||||
| press-on solid tyre | ||||||
| solid rubber tires with rims | ||||||
Company Information:
Yantai Wonray Rubber Tire Co., Ltd. is a comprehensive enterprise engaged in researching, producing and selling industrial tires with high performance at low costs. Our annual production capacity is 300,000 pieces, among which 40% products are exported to oversea markets like North America, Europe, Southeast Asia, Oceania, Africa, etc. Our sales network spreads all over China, and we can provide excellent and complete after-sales services for all customers.
Products and factory photo show:
After Sales:
1, All our solid tires are in line with GB/T10824-2008
2, We will advise the speed limit and load capacity after sales
3, If any problem, please contact with us, we will reply in short time.
4, If quality problem, although it is rare, please take photos, we will be responsible for this.
5, For the need of developing new product, please offer us detailed technical requirement or mould drawing.
Attention:
We have rims with different installing bolt holes. When ordering these tires with rims, please let us know how many bolt holes your current rims have!
For more sizes and information please call us or leave message:
Ms Kelly Ma 24 hours service phone 86 13884937497
