Insulated pvc coated copper tube for air conditioner and refrigeration
---Wuxi Boro Special Steel Company
Specifications of Capillary copper tube:
1 Grade:C10200 C12200 etc.
2 Outside diameter: 1.6mm-5mm
3 Thickness: 0.27mm-2.0mm
4 Coil weight: 5kg/20kg/30kg/50kg
5 Process Method: cold drawn and cold rolled
6 Surface: pickled or sand blasting
| Specifications | Unit weight | O.D | I.D | Bottom Wall Thickness TW | Fin Groove Depth HF | TotalWallThickness | Apex Angle | Helix Angle | Number of Tooth |
| Φ5.00×0.20+0.15-18° | 33 | 5.00 | 4.30 | 0.2 | 0.15 | 0.35 | 40 | 18 | 40 |
| Φ7.00×0.25+0.10-15° | 52 | 7.00 | 6.30 | 0.25 | 0.10 | 0.35 | 40 | 15 | 65 |
| Φ7.00×0.25+0.18-18° | 57 | 7.00 | 6.14 | 0.25 | 0.18 | 0.43 | 40 | 18 | 50 |
| Φ7.00×0.25+0.22-16° | 58 | 7.00 | 6.06 | 0.25 | 0.22 | 0.47 | 22 | 16 | 54 |
| Φ7.00×0.27+0.15-18° | 60 | 7.00 | 6.16 | 0.27 | 0.15 | 0.42 | 53 | 18 | 60 |
| Φ7.94×0.25+0.18-18° | 65 | 7.94 | 7.08 | 0.25 | 0.18 | 0.43 | 40 | 18 | 50 |
| Φ7.94×0.25+0.20-18° | 66 | 7.94 | 7.04 | 0.25 | 0.20 | 0.45 | 40 | 18 | 50 |
| Φ7.94×0.26+0.17-18° | 66 | 7.94 | 7.08 | 0.26 | 0.17 | 0.43 | 40 | 18 | 50 |
| Φ7.94×0.28+0.20-18° | 72 | 7.94 | 6.98 | 0.28 | 0.20 | 0.48 | 40 | 18 | 50 |
| Φ7.94×0.30+0.20-18° | 76 | 7.94 | 6.94 | 0.3 | 0.20 | 0.50 | 40 | 18 | 50 |
| Φ9.52×0.27+0.16-18° | 82 | 9.52 | 8.66 | 0.27 | 0.16 | 0.43 | 30 | 18 | 70 |
| Φ9.52×0.28+0.12-15° | 80 | 9.52 | 8.72 | 0.28 | 0.12 | 0.40 | 53 | 15 | 65 |
| Φ9.52×0.28+0.15-18° | 83 | 9.52 | 8.66 | 0.28 | 0.15 | 0.43 | 53 | 18 | 60 |
| Φ9.52×0.28+0.15-25° | 88 | 9.52 | 8.66 | 0.28 | 0.15 | 0.43 | 90 | 25 | 65 |
| Φ9.52×0.28+0.20-18° | 85 | 9.52 | 8.56 | 0.28 | 0.20 | 0.48 | 25 | 18 | 55 |
| Φ9.52×0.28+0.20-18° | 88 | 9.52 | 8.56 | 0.28 | 0.20 | 0.48 | 40 | 18 | 60 |
| Φ9.52×0.30+0.20-18° | 90 | 9.52 | 8.52 | 0.3 | 0.20 | 0.50 | 30 | 18 | 60 |
| Φ9.52×0.30+0.20-18° | 94 | 9.52 | 8.52 | 0.3 | 0.20 | 0.50 | 53 | 18 | 60 |
| Φ9.52×0.34+0.15-25° | 104 | 9.52 | 8.54 | 0.34 | 0.15 | 0.49 | 90 | 25 | 65 |
| Φ9.52×0.40+0.25-18° | 123 | 9.52 | 8.22 | 0.4 | 0.25 | 0.65 | 40 | 18 | 60 |
| Φ12.00×0.36+0.25-18° | 140 | 12.00 | 10.78 | 0.36 | 0.25 | 0.61 | 40 | 18 | 70 |
| Φ12.70×0.35+0.25-18° | 155 | 12.70 | 11.50 | 0.35 | 0.25 | 0.60 | 53 | 18 | 70 |
| Φ12.70×0.40+0.25-18° | 170 | 12.70 | 11.40 | 0.4 | 0.25 | 0.65 | 53 | 18 | 70 |
| Φ12.70×0.50+0.25-18° | 201 | 12.70 | 11.20 | 0.5 | 0.25 | 0.75 | 53 | 18 | 75 |
| Φ12.75×0.36+0.21/0.25-20° | 150 | 12.75 | 11.53 | 0.36 | 0.25 | 0.61 | 48 | 20 | 70 |
| Remark:These are common sizes which the company is making,and unusaal sizes with special requirement can be tailor-made against order. | |||||||||
Inspection for Capillary copper tube :
Chemical Analysis -- Component Analysis--- Spectroscopic Analysis--- Physical Property Inspection--- Eddy Current Inspection - Ultrasonic Inspection
Mill Test Certificate is supplied with shipment
Third Part Inspection is acceptable
Features of Capillary copper tube:
1) Small external diameter
2) High precision
3) Smooth internal and external surface
Applications of Capillary copper tube:
1) Air Conditioner and Refrigerator
2) Water Tube service and Distribution
3) Fire Protection, Solar, Fuel/Fuel Oil
4) Natural Gas, Liquefied Petroleum (LP) Gas
5) HVAC, Snow Melting, Drain, Waste, Vent Piping
6) Heat Exchange
Wuxi Boro Special Steel Co.,Ltd has been steel line for many years....Our main products are stainless steel/copper/aluminum sheet,coil,pipe/tube,bar. Maybe our company is not biggest,But our company service and quality must be best!!! Every new customer will get our best service as like our VIP clients.
We have exported to so many countries,such as Venezuela,Mexico,Israel,Malaysia,Vietnam,Egypt,Indonesia,USA,Philippines,Greece,Maldives,Ukraine,Chile,
Thailand,Sri Lanka,Angola,Morocco,Poland,Dubai,Kazakhstan,etc.
Quality is our culture!
Work with us,You will be happy!
Your money will be safe!
Any questions or enquiry,welcome to contact us at once!!!
We work for you at 24 hours!!!
Contact: Ms.Angelina
Whatsapp/Mobile: 0086-18262294060
Skype: live:angelina_170
Wechat: gxf18262294060
