We produce the products on the assenmbly line,every working process is strict to ensure high quality of each hoist.
Specifications 250/500KG Lifting Machine
1.with urgent stop switch
tection class up to IP54
3.with thermal protection devic
4.Work Duty: S3-25%-10min(it works 2.5min & rests 7.5min in one wor period of 10min)
5.Group of mechanisms M1
6.Rated Current: 2.0A
7.Diameter of wire rope: 3.05-5.6mm
8.Tensile strength of wire rope ≥ 1870N/mm2
9.Harmonization System (HS) Code:8425 1100
Security Assurance:
1.Reinforced breaking limit switch: When the hoist lifts to touch the directional stop, the switch will be disconnected, in order to prevent hooks from being twined into the rope drum.
2.Protection class that is up to IP40 can ensure it has a long operating life.
3.Thermal prevention device :It takes aluminum to make its housing to get a best heat radiation.
4.The spindle is made by the latest strong magnetic chip to assure the motor’s lifting strength.
Structure Features :
We use the world's leading technology to make internal structure. Engineers adopt high-density aluminum to diecast it to be rotors to ensure the speed of rotor is not lower than the motor’s specified speed.
Kindly Reminder:
1.Please don’t overload or lift the goods which its weight is unclear.
2.Don’t use it too long.
3.Please put on your thicken leather gloves to operate the wire rope ,but when it works, don’t pull the tight rope or work below or near it.
4.Before it works, pls ensure it runs without barriers, and don’t use it to lift people.
5.Don’t optionally modify or weld components of the product.
Application:
This product is widely used in small and medium-sized enterprises, transportation industry, seafaring, agriculture.It can be installed in the indoor, the outdoor,the balcony and the roof, and can be used for small construction project, installing protective screening, advertising board and storing fruits ,dring grains in the sun.
