Automatic Generator Controller BC118
Generator Controller BC118 is one light and low-cost orientated controller used for diesel engine and generator. It can be started/stopped by external key switch or the front face buttons. There are DC Current and running indications, what’s more, Over-speed, High Water Temperature,Low Oil Pressure, Over-Crank, Emergency Stop and Battery Voltage can be monitored so that the defaults can be checked easily.
All outputs function executed by a set of traditional relays which make it possible to support heavy power handling capability. It designed to control engine by a key switch. User only needs to switch the key to the Manual position then the system will carry out whole functions according your settings. Besides, the BC-68 applied with a high security continental terminal connector that provides easy plug-in and removal.
u Main Features
ü Micro-computer control
ü LED Alarm Indicators
ü Parameters set by dial switch on the back which can be applied to various engines.
ü External Start Key or Buttons
ü Specially designed for renters and bad environment available.
u Protection
ü Emergency Shutdown
ü Low Battery Warning
ü Over Speed Shutdown
ü High Coolnat Temp Shutdown
ü Low Oil Pressure Shutdown
u Protections and parameters
ü Emergency shutdown protection: 1 sec.,N.C
ü Low battery warning: 5 sec.,10.5 / 21 VDC
ü Over speed protection: 2 sec., 55/66 Hz
ü High water temp protection: 2 sec., N.O
ü Low oil press Protection: 2 sec., N.C/N.O
ü Over crank: 3 attempts
ü Cranking speed up limited: 0.5 sec. 16 Hz
ü Protection hold-off timer: 5 sec.
u Specifications
ü Dc Supply:DC 8~36 V
ü Power Consumption:MAX 5 W
ü Measuring Frequency :0~80 Hz (AC Volt: 25 V ~ 300 V)
ü Relay Output
Start output :2A
Valve output :2A
Idle / Pre-heat output :2A
Alarm output :2A
Stop output :2A
ü Dimension (W * H * D):72mm * 72mm * 58mm
ü Panel Cut-Out (W * H):67mm * 67mm
ü Ambient Temperature Range:-10℃ ~ 65℃
ü Weight 200 g
We provide other models of generator controllers:
| NO | Name | Model No |
| 1 | Generator controller | GC30D |
| 2 | Generator controller | BC118 |
| 3 | Generator controller | BC168 |
| 4 | Generator controller | BC180 |
| 5 | Generator controller | DC20D |
| 6 | Generator controller | DC40D |
| 7 | Generator controller | BC501K |
| 8 | Generator controller | BC520A |
| 9 | Generator controller | BC3000 |
| 10 | Generator controller | BC5110 |
| 11 | Generator controller | BC5110-DS |
| 12 | Generator controller | BC5120 |
| 13 | Generator controller | BC5210 |
| 14 | Generator controller | BC5220 |
| 15 | Generator controller | BC701MS |
| 16 | Generator controller | BC701K-AS |
| 17 | Generator controller | BC702MS-HC |
| 18 | Generator controller | BC702AS-HC |
| 19 | Generator controller | BC703 |
| 20 | Generator controller | BC704 |
| 21 | Generator controller | BC705 |
| 22 | Generator controller | BC710 |
| 23 | Generator controller | BC720 |
| 24 | USB | P810 |
| 25 | Step Speed controller | ESM3012 |
| 26 | Actuator | ASM5676 |
| 27 | Actuator | ASM5654 |
| 28 | Engine Control Box | BX341 |
| 29 | Engine Control Box | BX40 |
| 30 | Generator set Control Box | BX5XXX ORIGINAL VERSION |
| 31 | Engine interface card | EIM630-465/466 |
If you are interested in any of them, please feel free to contact us for more
information. ^_^
