Specifications
demister1.Convenience of installing, operating and repairing
2.ISOcertified
3.High porosity, less pressure drops.
Product Desciption
Wire-mesh demister(or mist eliminator)is mainly used to separate drops of the diameter between 3μ M to 5μ M. When the gas with liquid drops rises at a certain speed, passing through the wire mesh on the grid bar, the inertia of the rising drops make them collide with the wire and then adhere to the surface of the wire. The drops on the wire will diffuse and subside.
It makes the drops form bigger ones and then flow along the wire to the intertexture of the wire. Because the wire can be humidified, and because of the surface tension of liquid and the capillarity effect of the wire, the drops will become bigger and bigger. They will be separated and fall when their own weight exceed the resultant force of buoyancy of the rising gas and surface tension of liquid. They will flow to the device of the container in the backward position.
As long as the speed of the gas is properly controlled and with other proper condition, the efficiency of foam remove will be as high as 97% after the gas pass through wire-mesh demister. The purpose of removing foam will be achieved completely.
Standard type
Material: 302,304,304 L, 316,316 L, 317
Specifications are as follows:
Model :40-100 60-150 ,140-400
Common diameter :0.23-0 .28mm
Form code: SP
Weight capacity: 168 Kg/m3
Specific surface area: 529.6 m2/m3
Porosity : 0.97
the characteristic of wire-mesh demister
Structure simple, weight light.
High factor of porosity, low head loss.
Great contact surface area, high removing foam ratio.
Convenience of installing, operating and repairing.
Long service life.
China standard of wire-mesh demister
Wire mesh demisters uses:
Chemical, petroleum, sulfate, medicine, light industry, metallurgy, machine, building, construction, aviation, shipping and environment protection. Demister pad is mainly used to eliminate streams with diameter of more than 3μm to 5μm.
Features: Simple structure, light, less pressure drop, big surface, high demisting efficiency, easy installation, operation and maintenance and long service life.
