Help Center8" White Rice Husk Rubber Roller
Related Products
-
White Iron Drum Rice Shell Rubber RollerNegotiableMOQ: 100 Pieces -
Wheat Grain and Wheat Husk Importer Rubber RollerNegotiableMOQ: 100 Pieces
-
White Iron Drum Rice Shell Rubber RollerNegotiableMOQ: 100 Pieces
-
Epdm Iron Drum Rice Shell Rubber RollerNegotiableMOQ: 100 Pieces
-
Equipment Importer in Hyderabad Rubber RollerNegotiableMOQ: 100 Pieces
- The iron drum and aluminum drum can be options.;
- Good wear-resisting;Hardness is 90 ~95 degrees;
- Offering very strong bonding between rubber and drum;
- High shelling efficiency up to 95%;
Specification of Rubber rollers
Type |
Wheel Type |
|
Type No |
LGL-20.0 |
|
Specifications (inch) |
8’ |
8’(Large) |
Outside diameter(mm) |
223±1 |
254±1 |
Length (mm) |
200±1 |
200±1 |
Carton size(mm) |
450*240*210 |
------ |
G.W(KG) |
18 |
------ |
Piece per carton (PCS) |
2 |
------ |
Rubber Roller Character:
- Elastic stiffness, Strong plasticity under the high hardness, moderate grain force, high roughness, low cardamine.
- Good wear resistance, long using period.
- Strong temperature, no climate impact, not deformation, soft, anti-tear at high-speed.
- Health and non-toxic, no pollution to rice and bran, clean, bright white grain of rice, pure color quality.
Series of Products of Hulling Rubber rollers | ||||
Number |
Item |
Size |
Drum |
Color |
1 |
SBR |
8’ |
Cast Iron |
Brown |
2 |
SBR |
8’ |
Cast Iron |
White |
3 |
NBR |
8’ |
Cast Iron |
Brown |
4 |
NBR |
8’ |
Cast Iron |
White |
5 |
POLY |
8’ |
Csat Iron |
White |
|
|
Large Size |
|
|
6 |
SBR |
8’(large) |
Cast Iron |
Brown |
7 |
SBR |
8’(large) |
Cast Iron |
White |
8 |
NBR |
8’(large) |
Cast Iron |
Brown |
9 |
NBR |
8’(large) |
Cast Iron |
White |
10 |
POLY |
8’(large) |
Csat Iron |
White |
Usage:
Rice hulling rubber is the main part of rice huller machine, because of speed difference of veer and reversion between two rubber rollers, paddy are torn up by two rubber rollers, in the end, rice grains come out.
NBR roller is the 2nd generation of rice huller rubber roller, is adopted 100% NBR rubber materials, the original color is Amber with innocuity, and its outputs will be two or three times more than SBR roller at least.
Attentions:
- Handle carefully during the transportation.
- Store in dry place, away from Acid, Alkali, Salt, oil, and dirty, forbidden to put under sun for long time.
- Take sands away from the paddy, keep paddy dry and cleaning when using the rollers.
- Two roller should be at the same lever, the space must be equal.
- The paddy inputting should be keep the balance.
- keep the rate of the re-hulling under the limited
- Don’t make the machine work for a long time, in case effect the hulling capacity.
- The surrounding temperature is better under the 50°C.
- Change the fast and slow roller at a certain time.
OEM order with your logo is accept . If you need other size and specification rubber roller , please provide detailed specification or send sample to us , we can creat to supply it for you .
