Home > Manufacturing & Processing Machinery > Agricultural Machinery > Sheller > Rubber Huller Roller,rice Polisher Rubber
Rubber Huller Roller,rice Polisher Rubber
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Hulling Rubber Roller
Use:
Process the rice
Payment & Shipping
Payment Methods:
Port of Shipment:
Wuhan port Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Rice Rubber Rolls In Rice Mill MachineNegotiableMOQ: 100 Pieces -
8" White Rice Husk Rubber RollerUS$ 20 - 38MOQ: 100 Pairs
-
White Iron Drum Rice Shell Rubber RollerNegotiableMOQ: 100 Pieces
-
Wheat Grain and Wheat Husk Importer Rubber RollerNegotiableMOQ: 100 Pieces
-
White Iron Drum Rice Shell Rubber RollerNegotiableMOQ: 100 Pieces
Condition
New
Type
Hulling Rubber Roller
Use
Process the rice
Place of Origin
Hubei, China
Brand Name
Roaring Lion Qiaowang
Model Number
SBR/NBR/POLY
After-sales Service Provided
Overseas service center available
Specifications
1.more than 20 years of experience.2.Cast Iron Drum,Aluminium Drum
3.Got ISO9001-2008 certification
4.6inch rubber roller
Brand Name: Roaring Lion, Qiaowang, OEM brand
Size: 4 inches,6 inches,7 inches, 8 inches,10 inches,14 inches,20 inches, 25 inches, 28 inches
Material: SBR, NBR, POLY
Color: Brown, White, Amber
Specification of Rubber rollers
Type |
Wheel Type |
|
Type No |
LGL-15.2 |
|
Specifications (inch) |
6’ |
6’(Large) |
Outside diameter(mm) |
223±1 |
325±1 |
Length (mm) |
152±1 |
152±1 |
Carton size(mm) |
520*270*280 |
------ |
G.W(KG) |
26 |
------ |
Piece per carton (PCS) |
4 |
2 |
Information:
Chibi Doulbe Lion’s rice rubber roller are made of strong and light iron drum or aluminum drum. The rice rubber roller works steadily with high efficiency, low rate of broken rice;
Rubber Roller Character:
- Hardness is 90 ~95 degrees;
- Excellent in heat and abrasion resistance;
- Offering very strong bonding between rubber and drum;
- High shelling efficiency up to 95%;
- The SBR and NBR rice huller rubber roller can be options.
- Elastic stiffness, Strong plasticity under the high hardness, moderate grain force, high roughness, low cardamine.
- Good wear resistance, long using period. trong temperature, no climate impact, not deformation, soft, anti-tear at high-speed.
- Health and non-toxic, no pollution to rice and bran, clean, bright white grain of rice, pure color quality.
Usage:
- Rice hulling rubber is the main part of rice huller machine, because of speed difference of veer and reversion between two rubber rollers, paddy are torn up by two rubber rollers, in the end, rice grains come out.
- NBR roller is the 2nd generation of rice huller rubber roller, is adopted 100% NBR rubber materials, the original color is Amber with innocuity, and its outputs will be two or three times more than SBR roller at least.
- Aluminium drum rubber roller, with its light weight, high concentricity, the wear-resisting performance is good. It makes the machine to reduce the load vibration, and to increase the rubber roller's life.
- We are pleasure to offer the main styles of hulling rubber rollers in our company. Our enterprise also can design special product according to your individual requirement.
Attentions:
- Handle carefully during the transportation.
- Store in dry place, away from Acid, Alkali, Salt, oil, and dirty, forbidden to put under sun for long time.
- Take sands away from the paddy; keep paddy dry and cleaning when using the rollers.
- Two rollers should be at the same lever, the space must be equal.
- The paddy inputting should be keeping the balance.
- keep the rate of the re-hulling under the limited
- Don’t make the machine work for a long time, in case effect the hulling capacity.
- The surrounding temperature is better under the 50°C.
- Change the fast and slow roller at a certain time.
OEM order with your logo is accept . If you need other size and specification rubber roller , please provide detailed specification or send sample to us , we can creat to supply it for you .
Series of Products of Hulling Rubber rollers | ||||
Number |
Item |
Size |
Drum |
Color |
1 |
SBR |
6’ |
Cast Iron |
Brown |
2 |
SBR |
6’ |
Cast Iron |
White |
3 |
NBR |
6’ |
Cast Iron |
Brown |
4 |
NBR |
6’ |
Cast Iron |
White |
5 |
POLY |
6’ |
Csat Iron |
White |
|
|
Large Size |
|
|
6 |
SBR |
6’(large) |
Cast Iron |
Brown |
