Specifications
automobiles&motorcycles bearing 60031.easy to use
2.support high axial load
3.low friction coefficient
4.ISO:9001:2000
Chinese brands automobiles & motorcycles beearing 6003 series deep groove ball bearing
Brief introduction
Deep groove ball bearing is the Rolling the most common one type. The basic type of deep groove ball bearings into an outer ring, an inner ring, a set of steel balls, and a group of holding architecture. Deep groove ball bearing type single and double row two, single row deep groove ball bearing type code for 6, double row deep groove ball bearings Code 4. Its structure is simple, easy to use, is the production of the most common, the most widely used type of bearings.
Deep groove ball bearings mainly take radial load as well as both radial and axial load. When only radial load, the contact angle is zero. When deep groove ball bearings with radial clearance with the performance of angular contact bearings, can withstand large axial load, deep groove ball bearings, the friction coefficient is small, the speed is also high.
Deep groove ball bearing structure is simple, easy to achieve high manufacturing precision compared with other types, so easy to become a series of high-volume production, lower manufacturing costs, a very common use. Deep groove ball bearings in addition to the basic type, there are a variety of variable-type structure, such as: Shielded deep groove ball bearings, deep groove ball bearings with rubber seals, stopper groove deep groove ball bearings, mounted the the ball gap large load capacity of the deep groove ball bearings, double row deep groove ball bearings.
Bearing Type
1, single row deep groove ball bearings
2, single row deep groove ball bearings with dust cover
3, with dust cover, seal ring of single row deep groove ball bearings
4, the outer ring on the stopper groove and snap ring of single row deep groove ball bearings
5, deep groove ball bearings with filling slots
6, double row deep groove ball bearings
In accordance with the size of the deep groove ball bearings can be divided into:
(1) miniature bearings ---- nominal diameter size range of less than 26mm of bearing;
(2) small bearing ---- nominal diameter size range of 28-55mm bearings;
(3) small and medium-sized bearings ---- nominal diameter size range of 60-115mm bearing;
(4) in the large bearing ---- nominal diameter size range of 120-190mm bearings
(5) large bearing ---- nominal diameter size range of 200-430mm bearing;
(6) large bearings ---- nominal diameter size range of 440mm above the bearing
Specifications:
6003 series Sealed Ball Bearings, Bearing is made of Chrome Steel, each 6003-2RS bearing has 2 Rubber Seals to protect the bearing from dust or any possible contamination, 6003-2RS bearings are pre-lubricated with grease, Bearings 6003-2RS are packed 10 bearings in one plastic tube.
- Item: 6003 series Ball Bearing
- Type: Deep Groove Ball Bearings
- Closures: Rubber seals
- Lubrication: Self Lubricated (Grease)
- Size: 17mm x 35mm x 10mm
- Inner Diameter: 17mm
- Outer Diameter: 35mm
- Width: 10mm
- Quantity: 10 Bearings
- Dynamic load rating Cr: 6,000 N
- Static load rating Cor: 3,250 N
-
Limiting Speed:Common Applications: Go karts, electric motor
- Grease Lubrication: 14,000 RPM
- Equal: 6003-2RS1 & 6003RS
Parts of models:
Type |
Dimensions (mm) |
Basic Load Rating (N) |
Limiting Speed (rpm) |
Weight (Kg) |
|||||
d |
D |
B |
r (min) |
Dynamic |
Static |
Grease |
Oil |
||
625 |
5 |
16 |
5 |
0.3 |
1460 |
598 |
35000 |
42000 |
0.0048 |
626 |
6 |
19 |
6 |
0.3 |
2800 |
1058 |
32000 |
38000 |
0.0081 |
627 |
7 |
22 |
7 |
0.3 |
3310 |
1350 |
30000 |
35000 |
0.013 |
628 |
8 |
24 |
8 |
0.3 |
3330 |
1410 |
29000 |
34000 |
0.017 |
629 |
9 |
26 |
8 |
0.3 |
4550 |
1950 |
25000 |
31000 |
0.020 |
6200 |
10 |
30 |
9 |
0.6 |
5110 |
2390 |
23000 |
28000 |
0.032 |
6201 |
12 |
32 |
10 |
0.6 |
6800 |
3050 |
20000 |
24000 |
0.037 |
6202 |
15 |
35 |
11 |
0.6 |
7600 |
3680 |
17000 |
21000 |
0.045 |
6203 |
17 |
40 |
12 |
0.6 |
9580 |
4800 |
16000 |
19000 |
0.066 |
6204 |
20 |
47 |
14 |
1.0 |
12830 |
6650 |
14000 |
16000 |
0.106 |
6205 |
25 |
52 |
15 |
1.0 |
14020 |
7930 |
11000 |
13000 |
0.128 |
6206 |
30 |
62 |
16 |
1.0 |
19470 |
11430 |
9000 |
11000 |
0.199 |
6207 |
35 |
72 |
17 |
1.1 |
25700 |
15220 |
7800 |
9000 |
0.288 |
6208 |
40 |
80 |
18 |
1.1 |
29520 |
18140 |
6700 |
8000 |
0.366 |
6209 |
45 |
85 |
19 |
1.1 |
31660 |
20730 |
6800 |
7500 |
0.398 |
6210 |
50 |
90 |
20 |
1.1 |
35060 |
23220 |
6100 |
6300 |
0.454 |
6211 |
55 |
100 |
21 |
1.5 |
43500 |
29200 |
6400 |
7600 |
0.602 |
6212 |
60 |
110 |
22 |
1.5 |
52500 |
36000 |
6000 |
7000 |
0.789 |
Company introduction
Jinan Kelunte Bearing Co., Ltd. is a professional bearing manufacturer and is engaged in the imported bearings.
Our company is engaged in the imported bearings, bearings made of specialized companies, company's main imported brands, Domestic brands: Harbin HRB bearings, Wafangdian ZWZ bearings, Luoyang LYC bearings, and other major brands. Our products are widely used in automotive, electrical, petroleum, chemical machinery, engineering machinery, mine machinery, steel, railways, textile machinery and agricultural machinery, and other fields, the company adequate supply, inventory rich. Transportation is convenient, welcome new customers to visit us !
These products are widely used in metallurgy, power, petrochemical, construction machinery, railway, steel, papermaking, cement, mining and other industries.
With adequate supply, large stock and convenient transportation, we warmly welcome new customers to visit us.
1.Staff mission: to develop, innovation, cooperation and good faith.
2,Company's goals: a hundred years the name Enterprise, the industry fresh air.
3,Staff objectives: Choi-chi, with a minor, win-win progress.
4,Business philosophy: science and technology, quality, service, win-win situation.
5,Service spirit: Dissemination of cutting-edge technology together to create wealth.
6,Staff spirit: innovation, cooperation, sincerity and dedication.
7,Development strategy: the internationalization of enterprises to enter the brand name.
8,The core concept: the market conception of qualified personnel, learning concept.
