Japan Nachi Bearing Mechanical Parts Deep Groove Ball Bearing 6007

Japan Nachi Bearing Mechanical Parts Deep Groove Ball Bearing 6007 thumbnail-1
Japan Nachi Bearing Mechanical Parts Deep Groove Ball Bearing 6007 thumbnail-2
Japan Nachi Bearing Mechanical Parts Deep Groove Ball Bearing 6007 thumbnail-3
Japan Nachi Bearing Mechanical Parts Deep Groove Ball Bearing 6007 thumbnail-4
Japan Nachi Bearing Mechanical Parts Deep Groove Ball Bearing 6007 thumbnail-5
Japan Nachi Bearing Mechanical Parts Deep Groove Ball Bearing 6007 thumbnail-6
Japan Nachi Bearing Mechanical Parts Deep Groove Ball Bearing 6007 photo-1
Japan Nachi Bearing Mechanical Parts Deep Groove Ball Bearing 6007 photo-2
Japan Nachi Bearing Mechanical Parts Deep Groove Ball Bearing 6007 photo-3
Japan Nachi Bearing Mechanical Parts Deep Groove Ball Bearing 6007 photo-4
Japan Nachi Bearing Mechanical Parts Deep Groove Ball Bearing 6007 photo-5
Japan Nachi Bearing Mechanical Parts Deep Groove Ball Bearing 6007 photo-6
US$ 0.69 - 0.85 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Brand Name:
NACHI CLUNT
Bore Size:
35,
Outside Diameter:
62,
Contact Supplier Request Quote Chat Now
Jinan Kelunte Bearing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name NACHI CLUNT
Bore Size 35,
Outside Diameter 62,
Model Number 6007
Precision Rating P0 P6 P5 P4 P2
Seals Type OPEN RS 2RS Z ZZ
Number of Row Single Row
Place of Origin Shandong, China

Rolling bearing mechanical parts 6007 bearing & deep groove ball bearing

Deep groove ball bearings are the most common type of rolling bearings. Their use is very widespread. The raceway grooves on both the inner and outer rings have circular arcs of slightly larger radius than that of the balls. In addition to radial loads, axial loads can be imposed in either direction. Because of their low torque, they are highly suitable for applications where high speeds and low power loss are required.

In addition to open type bearings, these bearings often have steel shields or rubber seals installed on one or both sides and are prelubricated with grease. Also, snap rings are sometimes used on the periphery. As to cages, pressed steel ones are the most common.

Deep Groove Ball Bearings 6007

1

Material

Chrome Steel Gcr15 , Carbon steel Gcr11 , Stainless steel

2

Grease/Oil

Good quality

3

Cage

Steel , Brass , Nylon

4

Ball/Roller

Steel

5

Seal

Open, Z, ZZ, RS, 2RS, 2RZ, Oil seal

6

Package

1.Industry package: Plastic paper+Kraft paper,10pcs or 5pcs/roll

2.Plastic tube: 10pcs/tube or 5pcs/tube

3.Single box: plastic bag+single box, OEM supply

4.Single wooden box: plastic bag+single wooden box

5.Carton: Standard export carton(300X260X180MM) or as your need.

6.Pallet: Wooden or Iron pallet with plastic film against moisture.

7.Pallet size: 1200X900X750(mm), 0.81CBM

8.Package as your requirement

7

Bearing precision

P0(ABEC1) P6(ABEC3) P5(ABEC5) P4(ABEC7)

8

Noise

Z1V1 Z2V2 Z3V3

9

Quality

We have complete process for the production and quality assurance to make sure our products can meet your requirement.

1.Assembly

2.Windage test

3.Cleaning

4.Rotary test

5.Greasing and gland

6.Noise inspection

7.Appearance inspection

8.Rust prevention

9.Product packaging

10

Service

OEM

11

Application

Home appliances, low noise and high speed electric motors, automotive components, pumps, machinery.

12

Delivery

Normally ready goods and stock within 7 days

13

Payment Terms

30% T/T In Advance, 70% T/T Against Copy Of B/L or 100% LC at sight

15

Contact

13658640794



d 35  mm
D 62  mm
B 14  mm

D1 53,3  mm
Da max 57,4  mm
d1 43,2  mm
da min 39,6  mm
ra max 1  mm
rmin 1  mm

m 0,157  kg  Mass
Cr 17000  N  Basic dynamic load rating, radial
C0r 10300  N  Basic static load rating, radial
nG 16100  1/min  Limiting speed
nB 11600  1/min  Reference speed
Cur 550  N
  Fatigue limit load, radial





THE MAIN TYPE OF THE BEARINGS

604 series

605 606 607 608 609

623 series

623 624 625 626 627 628 629

634 series

634 635 638



61800 series

61800 61801 61802 61803 61804 61805 61806 61807 61808 61809 61820 61821 61822 61824 61826 61828 61834 61838 61840 61852 61860 61864 61872 61876 61880 61888 61892





61900 series

61900 61901 61902 61903 61904 61905 61906 61907 61908 61909 61910 61911 61912 61913 61914 61915 61916 61917 61918 61919 61920 61921 61922 61924 61926 61928 61934 61936 61938 61940 61944 61948 61952 61960 61964 61968 61980 61984 61988 61992



16001 series

16002 16003 16004 16005 16006 16007 16008 16009 16010 16011 16012 16013 16014 16015 16016 16017 16018 16019 16020 16021 16022 16024 16026 16028 16030 16032 16034 16038 16040 16052





6000 series

6000 6001 6002 6003 6004 6005 6006 6007 6008 6009 6010 6011 6012 6013 6014 6015 6016 6017 6018 6019 6020 6021 6022 6024 6026 6028 6030 6032 6034 6036 6038 6040 6044 6048 6052 6056 6060 6064 6068 6072 6080 6088 6092





6200 series

6200 6201 6202 6203 6204 6205 6206 6207 6208 6209 6210 6211 6212 6213 6214 6215 6216 6217 6218 6219 6220 6221 6222 6224 6226 6228 6230 6232 6234 6236 6238 6240 6244 6248 6252





6300 series

6300 6301 6302 6303 6304 6305 66306 6307 6308 6309 6310 6311 6312 6313 6314 6315 6316 6317 6318 6319 6320 6321 6322 6324 6326 6328 63306332 6334



6403 series

6403 6404 6405 6406 6407 6408 6409 6410 6411 6412 6413 6414 6415 6416 6417 6418 6419 6420 6422 6426
