KOYO Rollway Cylindrical Roller Bearing NU2314E With 70X150X51MM

KOYO Rollway Cylindrical Roller Bearing NU2314E With 70X150X51MM thumbnail-1
KOYO Rollway Cylindrical Roller Bearing NU2314E With 70X150X51MM thumbnail-2
KOYO Rollway Cylindrical Roller Bearing NU2314E With 70X150X51MM thumbnail-3
KOYO Rollway Cylindrical Roller Bearing NU2314E With 70X150X51MM thumbnail-4
KOYO Rollway Cylindrical Roller Bearing NU2314E With 70X150X51MM thumbnail-5
KOYO Rollway Cylindrical Roller Bearing NU2314E With 70X150X51MM thumbnail-6
KOYO Rollway Cylindrical Roller Bearing NU2314E With 70X150X51MM photo-1
KOYO Rollway Cylindrical Roller Bearing NU2314E With 70X150X51MM photo-2
KOYO Rollway Cylindrical Roller Bearing NU2314E With 70X150X51MM photo-3
KOYO Rollway Cylindrical Roller Bearing NU2314E With 70X150X51MM photo-4
KOYO Rollway Cylindrical Roller Bearing NU2314E With 70X150X51MM photo-5
KOYO Rollway Cylindrical Roller Bearing NU2314E With 70X150X51MM photo-6
US$ 25 - 30 MOQ: 20 Pieces
Key Specifications
Get Latest Price
Brand Name:
KOYO
Bore Size:
70,
Outside Diameter:
150,
Contact Supplier Request Quote Chat Now
Jinan Kelunte Bearing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name KOYO
Bore Size 70,
Outside Diameter 150,
Model Number NU2314E
Precision Rating P0 P6 P5 P4
Seals Type OPEN
Number of Row Single Row
Place of Origin Japan

KOYO Rollway Cylindrical Roller Bearing NU2314E with 70X150X51MM

Product Description

KOYO Rollway Cylindrical Roller Bearing NU2314E with 70X150X51MM



Single row cylindrical roller bearings

 This type of bearings are manufactured in several different designs, the main difference being in the configuration of the flanges. The most popular are the NU, N, NJ and NUP designs. Cylindrical roller bearings can accommodate heavy radial loads and high speeds.Some with different strcuture of ribs can also bear one way ot two way axial load.NN and NNU double row cylindrical roller bearings have a low cross section, high load carrying capacity and high stiffness,therefore it is mostly used in machine tool spindle stands.FC,FCD,FCDP four row cylindrical roller bearings with large capacity of radial load,mostly applied in rolling mill and heavy machine



Double-row Cylindrical Roller Bearing

 This type of bearings is separable.As their rollers linearly come into contact with inner ring and outer ring with less coefficient,these bearings have very good capacity of radial load,suitable for electric motors,automobiles,transmission shafts,gear shafts and so on.Double row cylindrical roller bearings are good at the spindles of spindles of machine tools.



Four-row cylindrical roller bearings
Four row cylindrical roller bearings can carry much heavier radial load and shock load. They have higher precision and can be applied in the equipment which runs with high rotational speed. Grinding the surface of raceway and roller at same time after the inner ring is pressed on roller neck, it favors the improvement of rolling precision and the free adjustment of mounting clearance of bearings. These bearings are mostly applied to the working roller and backup roller of rolling mills and some other cases.
FC: double outer rings, single inner ring, and inner without flange.
FCD: double outer rings, double inner rings, and inner ring without flange.

FCDP: double outer rings, only have center flange, but with loose rib, double inner ring, inner without flange.



Specifications of NU2314E



Bearing Code NU2314E
d 70
D 150
B 51
rsmin 2.1
Ew 133
Fw 89
Mass 4.02
CrkN 275
CorkN 325
Limiting speed 4500
D1min 82
D1max 87
D2min 92
D3min 100
D4max 138
D5min
D6max





NU series of cylinderical roller bearings

item dimension(mm)
  d D
NU202 15 35
NU203 17 40
NU204 20 47
NU2204 20 47
NU304 20 52
NU2304 20 52
NU205 25 52
NU2205 25 52
NU305 25 62
NU2305 25 62
NU405 25 80
NU206 30 62
NU2206 30 62
NU306 30 72
NU2306 30 72
NU406 30 90
NU207 35 72
NU2207 35 80
NU307 35 80
NU2307 35 100
NU407 35 80
NU208 40 80
NU2208 40 90
NU308 40 90
NU2308 40 110
NU408 40 85
NU209 45 85
NU2209 45 100
NU309 45 100
NU2309 45 100
NU409 45 120
NU210 50 90
NU2210 50 90
NU310 50 110
NU2310 50 110
NU410 50 130
NU211 55 10
NU2211 55 100
NU311 55 120
NU2311 55 120
NU411 55 140
NU212 60 110
NU2212 60 110
NU312 60 130
NU2312 60 130
NU412 60 150
NU213 65 120
NU2213 65 120
NU313 65 140
NU2313 65 140
NU413 65 160
NU214 70 125
NU2214 70 125
NU314 70 150
NU2314 70 150
NU414 70 180
NU215 75 130
NU2215 75 130
NU315 75 160
NU2315 75 160
NU415 75 190
NU216 80 140
NU2216 80 140
NU316 80 170
NU2316 80 170
NU416 80 200
NU217 85 150
NU2217 85 150
NU317 85 180
NU2317 85 180
NU417 85 210
NU218 90 160
NU2218 90 160
NU318 90 190
NU2318 90 190
NU418 90 225
NU219 95 170
NU2219 95 170
NU319 95 200
NU2319 95 200
NU419 95 240
NU220 100 180
NU2220 100 180
NU320 100 215
NU2320 100 215



Pictures of product

 KOYO Rollway Cylindrical Roller Bearing NU2314E with 70X150X51MMKOYO Rollway Cylindrical Roller Bearing NU2314E with 70X150X51MMKOYO Rollway Cylindrical Roller Bearing NU2314E with 70X150X51MMKOYO Rollway Cylindrical Roller Bearing NU2314E with 70X150X51MMKOYO Rollway Cylindrical Roller Bearing NU2314E with 70X150X51MMKOYO Rollway Cylindrical Roller Bearing NU2314E with 70X150X51MM



Company Information

KOYO Rollway Cylindrical Roller Bearing NU2314E with 70X150X51MMKOYO Rollway Cylindrical Roller Bearing NU2314E with 70X150X51MMKOYO Rollway Cylindrical Roller Bearing NU2314E with 70X150X51MM

Packaging & Shipping

KOYO Rollway Cylindrical Roller Bearing NU2314E with 70X150X51MM

Our Services
We are 100% manufacture. We can supply you technical support.
We have strict quality control processes. We supply high quality bearings with fair price.
We accept small quantity.
We may supply other globle brand bearings and offer buyer labels.
We can manufacture any bearings according to customer's drawings
FAQ

KOYO Rollway Cylindrical Roller Bearing NU2314E with 70X150X51MM
