Home > Industrial Equipment & Components > Bearing > Angular Contact Ball Bearing > ABEC9 4303A Bearing Fishing Reel Bearings 4303A All Bearing
ABEC9 4303A Bearing Fishing Reel Bearings 4303A All Bearing
US$ 2.1 - 160
MOQ: 10 Sets
Key Specifications
Get Latest Price
Brand Name:
CLUNT
Bore Size:
17,
Outside Diameter:
47,
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
5317 Bearing Angular Contact ABEC7 Ball Bearing 3317US$ 8.1 - 123.9MOQ: 20 Pieces -
Sweden Angular Contact Ball Bearing 7212 BearingUS$ 9.083 - 9.083MOQ: 1 Piece
-
3200 Series Double Row Angular Contact Ball Bearing 3206US$ 6.7 - 8.34MOQ: 100 Pieces
-
Angular Contact Ball Bearing 7001 With Nylon CageUS$ 1 - 1MOQ: 10 Sets
-
Chrome Steel Double Row Angular Contact Ball Bearing 5205US$ 2.45 - 3.69MOQ: 100 Pieces
Brand Name
CLUNT
Bore Size
17,
Outside Diameter
47,
Model Number
4303A
Precision Rating
P0 P6 P5 P4 P2
Seals Type
OPEN
Number of Row
Single Row
Place of Origin
Shandong, China
ABEC9 fishing reel bearings 4303A ball bearing
Four point angular contact bearings support high axial loads in both directions. The design provides high stiffness with minimum deflection. The split inner ring design also allows for high speeds when used with a machined cage. Available in bore dimension from 20mm to 240mm.
Specification of 4303A Angular Contact Ball Bearings
4303A 4-point angular contact ball bearings can accommodate high radial loads and thrust loads in both directions.
4303A angular contact ball bearings are particularly suitable for bearing arrangements requiring a rigid axial guidance.
4303A ball bearings are available as open basic design and with seals or shields at both sides.
| Bearing Model: | 4303A | ||||
| Bearing Brand: | CLUNT | ||||
| Bore Siz | 17mm | ||||
| Outside Diameter: | 47mm | ||||
| Clearance: | C3 | ||||
| Precision Rating: | P4 | ||||
| Cage Material: | Brass Cage | ||||
| Contact Angle: | 35° | ||||
| Cr(N): | 67 | ||||
| Cor(N): | 100 | ||||
ANGULAR CONTACT BALL BEARINGS WITH SPLIT INNER RACE | |||||||||
CYS |
Dimensions (Metric) |
Approx. |
Interchange |
||||||
Bearing NO. |
d |
D |
B |
Wgt. lbs |
CLUNT |
ntn | MRC |
NSK |
KOYO |
| QJ-205 | 25 | 52 | 15 | 0.35 | QJ205-MPA | 125-CDS | 9205-U | QJ 205 | QJ 205 |
| QJ-206 | 30 | 62 | 16 | 0.57 | QJ206-MPA | 130-CDS | 9206-U | QJ 206 | QJ 206 |
| QJ-207 | 35 | 72 | 17 | 0.78 | QJ207-MPA | 135-CDS | 9207-U | QJ 207 | QJ 207 |
| QJ-208 | 40 | 80 | 18 | 0.99 | QJ208-TVP | 140-CDS | 9208-U | QJ 208 MA | QJ 208 |
| QJ-209 | 45 | 85 | 19 | 1.15 | QJ209-TVP | 145-CDS | 9209-U | QJ 209 MA | QJ 209 |
| QJ-210 | 50 | 90 | 20 | 1.31 | QJ210-MPA | 150-CDS | 9210-U | QJ 210 MA | QJ 210 |
| QJ-211 | 55 | 100 | 21 | 1.7 | QJ211-TVP | 155-CDS | 9211-U | QJ 211 MA | QJ 211 |
| QJ-212 | 60 | 110 | 22 | 2.19 | QJ212-TVP | 160-CDS | 9212-U | QJ 212 MA | QJ 212 |
| QJ-213 | 65 | 120 | 23 | 2.69 | QJ213-MPA | 165-CDS | 9213-U | QJ 213 MA | QJ 213 |
| QJ-214 | 70 | 125 | 24 | 2.91 | QJ214-TVP | 170-CDS | 9214-U | QJ 214 MA | QJ 214 |
| QJ-215 | 75 | 130 | 25 | 3.24 | QJ215-TVP | 175-CDS | 9215-U | QJ 215 MA | QJ 215 |
| QJ-216 | 80 | 140 | 26 | 4.06 | QJ216-MPA | 180-CDS | 9216-U | QJ 216 MA | QJ 216 |
| QJ-217 | 85 | 150 | 28 | 4.98 | QJ217-MPA | 185-CDS | 9217-U | QJ 217 MA | QJ 217 |
| QJ-218 | 90 | 160 | 30 | 6.06 | QJ218-N2-MPA | 190-CDS | 9218-U | QJ 218 N2MA | QJ 218 |
| QJ-219 | 95 | 170 | 32 | 7.43 | QJ219-N2-MPA | 195-CDS | 9219-U | QJ 229 N2MA | QJ 219 |
| QJ-220 | 100 | 180 | 34 | 8.89 | QJ220-N2-MPA | 200-CDS | 9220-U | QJ 220 N2MA | QJ 220 |
| QJ-221 | 105 | 190 | 36 | 10.6 | QJ221-N2-MPA | 205-CDS | 9221-U | QJ 221 N2MA | QJ 221 |
| QJ-222 | 110 | 200 | 38 | 12.3 | QJ222-N2-MPA | 210-CDS | 9222-U | QJ 222 N2MA | QJ 222 |
| QJ-224 | 120 | 215 | 40 | 15.3 | QJ224-N2-MPA | 220-CDS | - | QJ 224 N2MA | QJ 224 |
| QJ-226 | 130 | 230 | 40 | 17.1 | QJ226-N2-MPA | 230-CDS | - | QJ 226 N2MA | - |
| QJ-228 | 140 | 250 | 42 | 21.7 | QJ228-N2-MPA | 240-CDS | - | QJ 228 N2MA | - |
| QJ-230 | 150 | 270 | 45 | 27.3 | QJ230-N2-MPA | 250-CDS | - | QJ 230 N2MA | - |
| QJ-232 | 160 | 290 | 48 | 34 | QJ232-N2-MPA | 260-CDS | - | QJ 232 N2MA | - |
| QJ-234 | 170 | 310 | 52 | 38 | QJ234-N2-MPA | 270-CDS | - | - | - |
| QJ-236 | 180 | 320 | 52 | 39 | QJ236-N2-MPA | 280-CDS | - | QJ 236 N2MA | - |
| QJ-238 | 190 | 340 | 55 | 50.7 | QJ238-N2-MPA | - | - | - | - |
| QJ-240 | 200 | 360 | 58 | 62 | QJ240-N2-MPA | - | - | QJ 240 N2MA | - |
| QJ-242 | 210 | 380 | 61 | 72.35 | - | - | - | - | |
| QJ-244 | 220 | 400 | 65 | 82.7 | QJ244-N2-MPA | - | - | - | - |
| QJ-246 | 230 | 420 | 68 | 96.35 | - | - | - | - | |
| QJ-248 | 240 | 440 | 72 | 110 | QJ248-N2-MPA | - | - | QJ 248 N2MA | - |
| QJ-250 | 250 | 460 | 76 | 125.5 | - | - | - | - | - |
| QJ-252 | 260 | 480 | 80 | 141 | - | - | - | - | |
