Brand Name CLUNT
Bore Size 17, 30
Outside Diameter 40, 60
Model Number 3203 2rs 3205 3206 2rs
Precision Rating P0 P6 P5 P4 P2
Seals Type 3203 2rs 3205 3206 2rs
Number of Row Single Row
Place of Origin Shandong, China

angular contact ball bearing 3203 2rs 3205 3206 2rs bearing



Double row angular contact ball bearing 3206 desciption:



Brand

Import or China brands

Model

3206

Seals

Open, Z, 2Z, 2RS

Specification(d*D*B)

30mm*62mm*23.8mm

Dynamic load

30 KN

Static load

20.4 KN

Limited speed

10000 r/min

Net weight

0.29kg



Features:
1) Withstand both radial load and axial load, with high rotation speed

2) Using the good raw material to ensure perfect quality

3) Scientific producing process and  Rigorous technical testing



Designs includes :

Includes three large categories : single -row angular , three -point ,four -point and double-row angular contact.



Single- row angular ball bearing accommodate radial loads ,acting simultaneously relative great axial load in one direction .

Series :70xx ,72xx,73xx,74xx,79xx,32xx,33xx, 38xx,39xx, non-standard series and inch series .

Contact angel calssifiled as C(15-degree),AC(25-degree)and B(40-degeree).

Nylon 66 cage ,but pressed steel cage can be supplied for some types .

Application : Single spindle, high frequency motor, and gas turbine, centrifuge, small cars front, differential pinions axis .

Double row: pumps, blower, air compressor, all kinds of transmission, fuel injection pump, printing machinery .



Double row Angular Contact Ball Bearing part numbers

open:3200, 3201, 3202, 3302, 3202, 5203, 3303, 3204, 5204, 3304, 5304,
3205, 5205, 3305, 5305, 3206, 5206, 3306, 5206, 3207, 5207, 3307,
5307, 3208, 5208, 3308, 5308, 3209, 5209, 3309, 5309, 3210, 5210,
3310, 5310, 3211, 5211, 3311, 5311, 3212, 5212, 3312, 5312, 3213,
5213, 3313, 5313, 3214, 5214, 3314, 5314, 3215, 3315, 5315, 3216,
3316, 3217, 3317, 3218, 3318, 3219, 3319, 3220, 3320, 3221, 3321,
3222, 3322,
ZZ: 5203ZZ, 5204ZZ, 5304ZZ, 5205ZZ, 5305ZZ, 5206ZZ, 5306ZZ, 5207ZZ,
5307ZZ, 5208ZZ, 5308ZZ, 5209ZZ, 5309ZZ, 5210ZZ, 5310ZZ, 5211ZZ,
5311ZZ, 5212ZZ, 5312ZZ, 5213ZZ, 5313ZZ, 5214ZZ, 5314ZZ, 5315ZZ,
2RS: 5203 2RS, 5204 2RS, 5304 2RS, 5205 2RS, 5305 2RS, 5206 2RS,
5306 2RS, 5207 2RS, 5307 2RS, 5208 2RS, 5308 2RS, 5209 2RS,
5309 2RS, 5210 2RS, 5310 2RS, 5211 2RS, 5311 2RS, 5212 2RS,
5312 2RS, 5213 2RS, 5313 2RS, 5214 2RS, 5314 2RS, 5315 2RS

Double-row Angular Contact Ball Bearing catalogue:



Bearing NO d D B KG
3200 10 30 14.3 0.051
3201 12 32 15.9 0.060
3202 15 35 15.9 0.069
3203 17 40 17.5 0.099
3204 20 47 20.6 0.166
3205 25 52 20.6 0.183
3206 30 62 23.8 0.303
3207 35 72 27.0 0.458
3208 40 80 30.2 0.627
3209  45 85 30.2 0.678
3210 50 90 30.2 0.698
3211 55 100 33.3 1.070
3212 60 110 36.5 1.340
3213 65 120 38.1 1.680
3214 70 125 39.7 1.840
3215 75 130 41.3 2.010
3216 80 140 44.4 2.710
3217 85 150 49.2 3.480
3218 90 160 52.4 4.24
3219 95 170 55.6 5.100
3220 100 180 60.3 5.880

  angular contact ball bearing 3203 2rs 3205 3206 2rs bearing pictures:
