Press on Solid Tyre 330x114x203.2

Press on Solid Tyre 330x114x203.2 thumbnail-1
Press on Solid Tyre 330x114x203.2 photo-1
US$ 35 - 1,000 MOQ: 20 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
TNR
Model Number:
330x114x203.2
Contact Supplier Request Quote Chat Now
Shuanglun Tires (Shanghai) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name TNR
Model Number 330x114x203.2

Specifications

1. Type: Standard, Click and Non -marking
2. Standard rim: 330x114x203.2
3. Suitable machinery: Forklifts

Characteristic:







Press-On tires are designed to provide maximum wear and energy efficiency.

Our innovative process permanently bonds the rubber to the rim for longer lasting performance.

Our premium compounds provide unique solutions for your particular tire needs.





The smooth pattern provides a greater contact area with the work
surface, offering better load distribution and subsequent
increased stability. The larger footprint area creates better
traction in most applications for both starting and stopping.
Smooth
• An Average 13% Greater Footprint Than
Standard Size
• Cooler Running For Longer Wear
• Improved Performance & Traction
• Increased Operator Comfort
• Available In All Compounds





1. Universal Compound
Designed as a general purpose compound, unique blend of synthetic and natural rubber provides cost effective operations on gas and electric trucks in most industrial applications.
2. Electric Compound
Engineered specifically for high cycle electric vehicles, electric tread is the choice major industries that demand extended service life and industry leading energy efficiencies for electric trucks in harsh applications.
3. High Performance Non-Marking (NM)
This revolutionary compound is the first to successfully combine energy efficiency and extended service life while maintaining Non-Marking performance.



Tech. Data:



Size Tread Pattern Weight
(KG)		 Maximum Loading
Forklift with Balance Weight Industrial Vehicles
10km/h 16km/h
mm in Driving wheel Steering Wheel Driving wheel Steering Wheel 16km/h
229x127x127 9x5x5 SM 7.5 890 790 850 785 685
254x102x158.8 10x4x6 1/4 SM 7.6 725 645 695 640 560
254x127x158.8 10x5x6 1/4 SM 8.2 955 850 910 845 735
254x152x158.8 10x6x6 1/4 SM 9.6 1180 1050 1130 1045 910
254x178x158.8 10x7x6 1/4 SM 11.2 1410 1255 1345 1245 1085
254x102x165.1 10x4x6 1/2 SM 7.9 720 640 690 635 555
254x121x165.1 10x4 3/4x6 1/2 SM 9.2 885 790 845 785 680
254x127x165.1 10x5x6 1/2 SM 8.4 940 835 900 830 725
254x152x165.1 10x6x6 1/2 SM 10.5 1160 1035 1110 1030 895
267x127x127 10 1/2x5x5 SM 9.0 1020 910 975 905 785
267x152x127 10 1/2x6x5 SM 10.4 1295 1155 1235 1145 995
267x102x165.1 10 1/2x4x6 1/2 SM 7.0 755 675 725 670 580
267x127x165.1 10 1/2x5x6 1/2 SM 8.8 1000 890 955 885 770
267x152x165.1 10 1/2x5x6 1/2 SM 10.6 1240 1105 1185 1100 955
267x178x165.1 10 1/2x7x6 1/2 SM 12.7 1485 1320 1415 1310 1140
305x114x203.2 12x4 1/2x8 SM 10.0 970 865 925 860 745
305x127x203.2 12x5x8 SM 11.2 1105 980 1055 975 850
305x140x203.2 12x5 1/2x8 SM 11.6 1240 1100 1180 1095 950
305x165x203.2 12x6 1/2x8 SM 13.8 1505 1340 1440 1330 1160
330x114x203.2 13x4 1/2x8 SM 11.2 1040 925 995 920 800
330x127x203.2 13x5x8 SM 12.5 1195 1065 1145 1060 920
330x165x203.2 13x6 1/2x8 SM 16.2 1665 1480 1590 1470 1280
343x140x203.2 13 1/2x5 1/2x8 SM 14.0 1400 1245 1335 1235 1075
343x165x203.2 13 1/2x6 1/2x8 SM 16.5 1730 1540 1650 1530 1330
381x127x285.8 15x5x11 1/4 SM 14.0 1290 1150 1235 1145 995
381x152x285.8 15x6x11 1/4 SM 16.0 1600 1425 1530 1415 1230
381x178x285.8 15x7x11 1/4 SM 18.7 1910 1700 1825 1690 1470
381x203x285.8 15x8x11 1/4 SM 21.1 2215 1975 2120 1960 1705
394x127x254 15 1/2x5x10 SM 14.9 1365 1215 1305 1210 1050
394x152x254 15 1/2x6x10 SM 18.1 1735 1545 1655 1535 1335
406x178x266.7 16x7x10 1/2 SM 22.4 2155 1915 2055 1905 1655
413x178x285.8 16 1/4x7x11 1/4 SM 22.6 2150 1915 2055 1900 1655
413x203x285.8 16 1/4x8x11 1/4 SM 25.8 2515 2235 2225 2020 1935
432x127x308 17x5x12 1/8 SM 17.4 1460 1300 1395 1295 1125
432x152x308 17x6x12 1/8 SM 20.8 1840 1635 1755 1625 1415
508x229x406.4 20x9x16 SM 35.8 3190 2840 3050 2820 2455
559x254x406.4 22x10x16 SM 47.4 4240 3775 4050 3750 3265
559x356x406.4 22x14x16 SM 64.9 6220 5535 5940 5500 4785
559x406x406.4 22x16x16 SM 74.2 7205 6415 6885 6375 5545
645x305x406.4   SM 83.0 6140 5465 5865 5430 4725
660x254x457 26x10x18 SM 725.5 5030 4465 4450 4040 3870
711x254x508 28x10x20 SM 79.9 5315 4715 4705 4265 4090
711x305x558.8 28x12x22 SM 81.2 6265 5575 5985 5545 4820
711x356x558.8 28x14x22 SM 92.8 7450 6630 7120 6590 5730
711x406x558.8 28x16x22 SM 106 8635 7685 8250 7640 6645
711x457x558.8 28x18x22 SM 138 9820 8710 8685 7880 7555
915x254x762 36x10x30 SM 127 6135 5460 5865 5430 4720
915x305x762 36x12x30 SM 138 7565 6735 7230 6695 5820
1016x305x762 40x12x30 SM 177 8865 7865 7845 7115 6820
1016x406x762 40x16x30 SM 233 12635 11210 11180 10140 9720







 Tyre picutures:press on solid tyre 330x114x203.2press on solid tyre 330x114x203.2
