Skid Steer Tire for GEHL 4840

Skid Steer Tire for GEHL 4840 thumbnail-1
Skid Steer Tire for GEHL 4840 photo-1
US$ 60 - 120 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
SUPERGRIP
Model Number:
10-16.5
Contact Supplier Request Quote Chat Now
Shuanglun Tires (Shanghai) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name SUPERGRIP
Model Number 10-16.5

Specifications

Skid Steer Tire for GEHL 4840
1. SUPERGRIP Skid steer tire 10-16.5 X88 14PR TL
2. Extra-Deep L5 Traction
3. Severe Duty

Skid Steer Tire for GEHL 4840

Extra-Deep L5 Traction

Patterns Availabe:

R4/ deeper L4/X'tra deep L5 / HF-3 /F-3 / Grass Floatation.

Pattern Details:

 R4

Features:
* Self-cleaning, open tread design for reduced maintenance time
* Extra large, tapered lugs for traction in slippery conditions and maximum wear life
* Reinforced dual sidewall for superior wear and resistance to cuts and abrasions
* Heavy rim guard reduces potential for damage to tire bead and wheel flange
* Improved productivity
* A smooth, stable ride for operator comfort

Applications:
* Dry Soil
* Wet Soil
* Rocky Soil
* Asphalt

L4
Features:
* Reinforced sidewall for superior tread stability and greater penetration resistance
* The deep tread provides for a long tread life and the center block tread resists “skid” wear

Applications:
* Quarries
* Rock & Shale
* Gravel
* Scrap Yard

Extra-Deep L5

Features:
* 14 ply rating enhances tear and puncture resistance
* Exceptional tread life resulting from low void-to-tread ratio
* Superior carcass strength allows the tire to bear extreme heavy load
* Exceptional traction and long wear

Applications:
* Quarries
* Rock & Shale
* Gravel
* Scrap Yard
* Asphalt
* Stone



Specifications:

SIZE P.R PATTERN TYPE T.D.  Std Rim Load Inflation Pressure Speed  S.W O.D
        (mm)   (lbs)  (psi) (mph) (mm) (mm)
10-16.5 14 x88 TL 42 8.25 6010 105 5 270 785
12-16.5 14 x88 TL 43 9.75 6780 90 5 315 861



Patterns Availabe:

R4/ deeper L4/X'tra deep L5

 R4

Features:
* Self-cleaning, open tread design for reduced maintenance time
* Extra large, tapered lugs for traction in slippery conditions and maximum wear life
* Reinforced dual sidewall for superior wear and resistance to cuts and abrasions
* Heavy rim guard reduces potential for damage to tire bead and wheel flange
* Improved productivity
* A smooth, stable ride for operator comfort

Applications:
* Dry Soil
* Wet Soil
* Rocky Soil
* Asphalt

Extra-Deep L5

Features:
* 14 ply rating enhances tear and puncture resistance
* Exceptional tread life resulting from low void-to-tread ratio
* Superior carcass strength allows the tire to bear extreme heavy load
* Exceptional traction and long wear

Applications:
* Quarries
* Rock & Shale
* Gravel
* Scrap Yard
* Asphalt
* Stone

Equivalent Brands:

Equivalent Brands: Part No.
Solideal
Goodyear Sure Grip Lug
Titan Contractor FWD I-3
CAT Premium Conventional Tires 185-9932
185-9933
238-7740
216-9111
216-9112
216-9113
208-8512
281-6590
281-6591
CAT XD Tires 222-3962
222-3963

MAIN Market

Aera %
Asia 0
Mideast 30
Africa 20
North America 10
South America 20
Europe 0
Australia 20
Others 0

Safty Instructions:

The tire itself, the following factors are very important:

  1.   Basic workmanship and materials.
  2.    Air pressure maintenance
  3.   Tyre matching
  4.   A rotation policy
  5.  Tyre records/analysis
  6.   Repair procedures

 Working site conditions, Including the following factors:

1.   Type of equipment

2.       Weight of distribution

3.       Speed

4.       Haul length

5.       Wheel position

6.       Ambient temperature

7.       Underfoot conditions

8.       Operator habits



Tips for using tires:

  1. Keep your tires clean by simply hosing them down.
  2.  Remove embedded rocks
  3. Wash off dirt
  4.  Always use approved tire and rim combinations for sizes and contours.
  5. Monitor and adjust air pressure, never exceed manufacturer’s recommended tire inflation pressure.
  6.  Consider the weight of your load and keep it balanced
  7.  Don’t spin the tires when digging.
  8.  Rotate tires that wear faster , replace any tires that appear to show signs of excessive wear, are damaged, or defective in any way,

 Which tire for which machines:

  CAT   BOBCAT   CASE   GEHL   JOHN DEER   MELROE BOBCAT   MUSTANG   NEW HOLLAND   RAM ROD   THOMAS   TOYATA
10-16.5 216   S130-S205   410-420   4515   240   S130-S205   920   L-465     516   T-103    2SDK8
  226       1835C    4610   313   742   930A    L-553   584   T-133
  228       1838   4615   315   743   940   L-555
  232       1840   4625   317   753        L-565
              4635   675   753L       L-585
              4835   4475   763       LS-140
              5625   5575   773       LS-150
              5635   6675   7753       LS-160
              6635   7775            LS-170
                              LX-465



12-16.5
  236   S220-S630   430-465       250   S220-S630   96   L-781    784   T-173
  242   A300   1845       260    853H   2060    L-783       T-203
  246       1845B       320   8853       L-785        T-233
  248       1845       325   843        L-865        T-243
  252               8875   873        L-885
  262                   8853       L-985
  268                   853       LS-180
  272                   853H        LS-190
                      863       LX-865





 PICTURES:

 Skid Steer Tire for GEHL 4840

Skid Steer Tire for GEHL 4840

Skid Steer Tire for GEHL 4840Skid Steer Tire for GEHL 4840Skid Steer Tire for GEHL 4840Skid Steer Tire for GEHL 4840Skid Steer Tire for GEHL 4840Skid Steer Tire for GEHL 4840Skid Steer Tire for GEHL 4840Skid Steer Tire for GEHL 4840Skid Steer Tire for GEHL 4840Skid Steer Tire for GEHL 4840Skid Steer Tire for GEHL 4840Skid Steer Tire for GEHL 4840



Skid Steer Tire for GEHL 4840
