Specifications
crawler excavator1.YANMAR engine from Japan.
2.Hydraulic motors are international famous brand.
3.Can works in narrow place.
Our company mainly product the construction machineries and heavy equipment. Such as road roller, wheel loader, bulldozer, motor grader and so on. We also can supply series spare parts of these machineries such as hydraulic pump, diesel engine, casting parts and so on. The more details please contact us.
Small crawler excavator WY6-3
1.The pictures of WY6-3 excavator.
2.The pictures of production line
3.The pictures of details of WY6-3 excavator
4.The main features and specifications
Main Features:
1. These crawler excavators are equipped with YANMAR engine which is energy saving and makes low noise .The exhaust emission conforms to Europe III standard.
2. Their variable and open-circuit hydraulic system, main pump, motor and valve are all purchased from internationally well-known manufacturers and are all of high reliability.
3. Monitor display and function control system are centralized in the I intellectualized mini-type control panel .Furthermore, an acoustic-optic alarm system is installed to ensure the normal operation.
4. The construction machinery is small in size and can revolve for 360 degree , so it can work in narrow places.
5. Various accessories are available, such as hammer, grab bucket, trimming-silt bucket so as to meet different specific operational requirements.
6. The rated power is 45KW. The rated speed is 2200 r/min. The maximum digging radius is 6100 mm. The maximum digging height is 5330 mm.
Product Parameters
Description |
unit |
WY6-3 |
Operating weight |
kg |
5800 |
Bucket capacity |
m3 |
0.22 |
Length/width/height |
mm |
5950×1920×2620 |
Engine model |
4TNV98-SSU |
|
Rated power/speed |
kW/r/min |
43.4/2200 |
Fuel consumption |
g/kw.h |
≤247 |
Fuel tank capacity |
L |
90 |
Rated flow |
L/min |
170 |
Implementation circuit |
Mpa |
22 |
Swing speed |
r/min |
0-10 |
Bucket digging force |
kN |
40 |
Arm digging force |
kN |
25 |
Max.traction force |
kN |
58.5 |
Traveling speed |
km/h |
0-2.3/0-4.4 |
Gradeability |
° |
30 |
Ground pressure |
kPa |
33 |
max.digging radius |
mm |
6150 |
max.digging height |
mm |
5515 |
max.dumping height |
mm |
3730 |
max.digging depth |
mm |
3820 |
overall length |
mm |
5950 |
crawler length |
mm |
2590 |
Wheelbase |
mm |
1990 |
counter weight ground clearance |
mm |
740 |
overall height |
mm |
2620 |
tail turning radius |
mm |
1650 |
roof width |
mm |
1850 |
crawler height |
mm |
645 |
min.ground clearance |
mm |
325 |
crawler width |
mm |
400 |
Crawler gauge |
mm |
1520 |
chassis width |
mm |
1920 |
earth-moving shovel(width/height) |
mm |
1920×320 |
Thanks for your attention to our product, If you are interested in our wheel loader or you need more other products, please contact me!
