pc strand wire high tensile steel strand wire
1, Q: What's the Payment method?
-A: 100% Irrevocable documentary L/C at sight; or 30% deposit in advance and the balance against copy B/L within 3 days.
2, Q: What's the Delivery port?
-A: Our factory can export from any port of China if you have special request.
3, Q: What's the delivery time?
-A: 20days upon receipt of advance deposit.
1) Authorized Certificates : ISO9001, SGS,BV.
2) Day Capacity: 300tons per day.
3) 22 years production experience.
4) Quality control: Advanced production line, necessary facility and examination equipment.
5) exporting to more than 40 countries.
pc strand wire high tensile steel strand wire usage:
Application: Bridges of large-scale railroads and highways, frame of roofs, overhead cran beams,industrial and civil prefabricated concrete slabs, wall boards, tubular piles, PC water pies, TV towers and nuclear power stations, etc.
high tensile steel strand wire Dimension Parameters:
Size/mm | Tolerance/mm | Area/mm2 | Theoretical weight-g/m | Wire Cross-sectional Size | Rib Pieces | Lay Length (Lg)/mm
| ||
Basic-roundDia (D1)/mm | OutioneDia(D)/mm | Rib Width(jk)/mm |
4 | |||||
4.00 | ±0.04 | 12.57 | 98.6 | 3.85±0.05 | 4.25±0.05 | 0.90~1.30 | 24-30 | |
4.80 | ±0.05 | 18.10 | 142 | 4.60±0.05 | 5.10±0.05 | 1.30~1.70 | 28-36 | |
5.00 | 19.63 | 154 | 4.08±0.05 | 5.30±0.05 | 1.30~1.70 | 28-36 | ||
6.00 | 28.27 | 222 | 5.80±0.05 | 6.30±0.05 | 1.60~2.00 | 30-38 | ||
6.25 | 30.68 | 241 | 6.00±0.05 | 6.70±0.05 | 1.60~2.00 | 30-40 | ||
7.00 | 38.48 | 302 | 6.73±0.05 | 7.46±0.10 | 1.80~2.20 | 35-45 | ||
8.00 | ±0.06 | 50.26 | 394 | 7.75±0.05 | 8.45±0.10 | 2.00~2.40 | 40-50 | |
9.00 | 63.62 | 499 | 8.75±0.05 | 9.45±0.05 | 2.10~2.70 | 42-52 | ||
10.00 | 78.54 | 616 | 9.75±0.05 | 9.75±0.05 | 2.50~3.00 | 45-58 | ||
Coil Weight: 800-1500kgs per coil.
Out Diameter: 1800-2200mm.
Inner Diameter: 1600-1800mm.
Package Paper: Water-proof kraft paper, pPP/ PE plastic woven strip, three layers packing.
Pls don't worry our loading products into containers, we have the forklift truck and loading platform, our packing also meet transport on the ocean.
Our Advantage:
Factory Directly Exported.
The best payment condition & Short Delivery Time.
We export ten thousand tons to 40 countries and regions in the last years. We also believe we can make a better achievement in future, and this need join in, pls contact us freely.
