high tensile steel wire
high tensile steel wire Advantage :
1.We are professional manufacturer
2.We have been approved by ISO9001:2008
3. We have whole set of production equipment and inspect instrument
high tensile steel wire Descriptions :
1.W.T: 2 MT- 4MT
2.Diameter : 4 -10MM
3.Material: High carton steel wire 77B, 82B
4.Tensile strength (TS) : 1470 1570 1670 1770 1860Mpa
7.Standard : GB/T5224(China)ASTMA421(USA);BS 896(UN);
JIS G3536(Japan);AS/NZS4672(Australia);NBR-7483(Brazil);
EN10138(Europe);ISO934
8. Type : PC strand, Prestresses concrete steel strand, Unboned pc strand, PC wire , Spiral pc wire ,Plain pc wire ,indented pc wire
9. Cerfificate : ISO9001:2000 SGS, China National Construction Steel Qulity Supervision and Test Centre Product Quality Supervision and Inspection Center, Ministry of Railways Railway Construction Inspection Station
high tensile steel wire Technical Specification :
1.Continued drawing with large deduction stranding then stabilizing treatment.
2.High rate of yield strength and ultimate strength, Low relaxation ,
Steady modulus of elasticity, stress relieved, high fixed with Concrete.
|
Nominal Diameter dn/mm |
Number of Spiral Ribs |
Lining Dimension |
Outline Dimension |
Single Rib Size |
Layer Length of Ribs C/mm |
||
|
Lining Diameter D1/mm |
Tolerance /mm |
Outline Diameter D/mm |
Tolerance /mm |
Width a/mm |
|||
4.00 |
4 |
3.85 |
±0.05 |
4.25 |
±0.05 |
0.90~1.30 |
24~30 |
4.80 |
4 |
4.60 |
5.10 |
1.30~1.70 |
28~36 |
||
5.00 |
4 |
4.80 |
5.30 |
||||
6.00 |
4 |
5.80 |
6.30 |
1.60~2.00 |
30~38 |
||
6.25 |
4 |
6.00 |
6.70 |
30~40 |
|||
7.00 |
4 |
6.73 |
7.46 |
±0.10 |
1.80~2.20 |
35~45 |
|
7.50 |
4 |
7.26 |
7.96 |
1.90~2.30 |
36~46 |
||
8.00 |
4 |
7.75 |
8.45 |
2.00~2.40 |
40~50 |
||
9.00 |
4 |
8.75 |
9.45 |
2.10~2.70 |
42~52 |
||
9.50 |
4 |
9.30 |
10.10 |
2.20~2.80 |
44~53 |
||
10.00 |
4 |
9.75 |
10.45 |
2.50~3.00 |
45~58 |
||
11.00 |
4 |
10.76 |
11.47 |
2.60~3.10 |
50~64 |
||
12.00 |
4 |
11.78 |
12.50 |
2.70~3.20 |
55~70 |
||
high tensile steel wire
