Help CenterWCB Series Modular Stabilized Soil Mixing Plant
Related Products
Introduction:
The WCB series modular stabilized soil mixing plant, adopting industrial microcomputer control system, has various advantages: even mixing, high productivity, multiple gradation, high modularization as well as easy installation, debugging and maintenance.
The equipment is widely applied to the construction of subbase in all kinds of highway, airports and so on.
Features:
1. Adopts international universal modular design, easy installation and quick change.
2. The batching station is equipped with profiled steel plates which are rigid and good-looking.
3. The electric components adopt the whole set of high-quality imported parts such as SCHNEIDER, SIEMENS and OMRON etc.world-famous brands, which are excellent and endurable.
4. Double operation of computer and console is realized to make operation simple and reliable.
5. Abnormal working conditions and breakdowns can be automatically detected, indicated through words, sound, light and warning, which makes it easy to find and fix the breakdowns.
Model |
WCB300 |
WCB400 |
WCB500 |
WCB600 |
|
Rated productivity(t/h) |
300 |
400 |
500 |
600 |
|
Volume of stone container(m3) |
3×12 |
3×12 |
4×15 |
4×15 |
|
Volume of cement measuring container(m3) |
7 |
7 |
9 |
4×15 |
|
Volume of finished material container(m3) |
8 |
8 |
10 |
10 |
|
Batching precision |
Aggregate |
±3% |
±3% |
±3% |
±3% |
Cement |
±1% |
±1% |
±1% |
±1% |
|
Water |
±1% |
±1% |
±1% |
±1% |
|
Aggregate particle size(mm) |
≤60 |
≤60 |
≤60 |
≤60 |
|
Material loading height(m) |
3.9 |
3.9 |
4.2 |
4.2 |
|
Material unloading height(m) |
3.1 |
3.1 |
3.1 |
3.1 |
|
Total power(kw) |
108 |
118 |
123 |
139 |
|
