ZLseries MINI Wheel Loader
Specifications
WSM mini wheel loader1.FOB:USD5200~14100
2.load capacity1~2T
3.Rated power:17~59kw
4.Mini wheel loader easy to operate
ZL12Wheel loader
Introduction
ZL12 wheel loader belongs to the hydraulic loader and is one of the engineering machinery. It is designed and produced with advanced technology from foreign and domestic machinery. It is widely used in the building working, municipal construction working, urban and rural gardens and other construction projects and so on.
The technical data
Model |
|
ZL12 |
Total weight |
kg |
2500 |
Bucket capacity |
m3 |
0.48 |
Rated loading weight |
kg |
1200 |
Min turning radius |
mm |
4120 |
Wheelbase |
mm |
1970 |
Minimum ground clearance |
mm |
200 |
Gearbox |
|
Belt box |
Front and rear axles |
|
Isuzu |
Tire |
|
825-16 |
Loading height |
mm |
2850 |
Unloading distance |
mm |
850 |
Max. grade ability |
|
30° |
Overall dimension(L/W/H) |
mm |
5150/1510/2460 |
Engine model |
|
2106 |
Engine rated power |
kW |
24 |
Performacne
- Rational design and compact structure.
- Flexible operation and convenient maintenance.
- The main parts of this series use product with famous brand.
- It has reliable quality.
