Descriptions
Circular Vibrating Screen is one of the unique product or equipment, it is used for separating the stuff. The circular vibrating screens work on circular motion. The vibrating screens are mainly used in coal dressing, metallurgy, mine, power station, water conservancy project, building industry, light industry and chemical industry etc They are efficient screening machines for the classification of bulk material such as coal, minerals, coke etc .
Vibrating screens work principle:
Vibrating Screen is compiled of mainframe, eccentric bock, screen web, rub spring, electric motor, coupler and some more. Vibrating Screen moves round .It has multi-layers and is of high efficiency. The eccentric shaft vibration exciter and partial block help to adjust amplitude. The material drops down along the long line.
circular vibrating screen main technical parameters:
Model |
No. of Layer |
Screen hole size (mm) |
Max. feed-in size(mm) |
Handling capacity (t/h) |
Motor power (Kw) |
Weight of machine(kg) |
2Yk1235 |
2 |
5-120 |
≤ 400 |
60-120 |
5.5 |
3600 |
3YK1545 |
3 |
5-150 |
≤ 400 |
110-385 |
15 |
6800 |
2YK1854 |
2 |
5-200 |
≤ 400 |
200-450 |
18.5 |
8600 |
3YK1860 |
3 |
5-200 |
≤ 400 |
250-600 |
22 |
9200 |
3YK2160 |
3 |
6-200 |
≤ 400 |
300-750 |
37 |
12800 |
3YK2460 |
3 |
6-200 |
≤ 400 |
400-850 |
45 |
14100 |
....
