Rotary drum dryer/drying machine
- 30 Set / Sets per Month
- China main port
- T/T
You May Like
-
Full technica support for rotary dryer for coal powder, sand, sawdust, clay--YUFENG Brand
-
Hot selling in India!!! rotary dryer for coal powder, sand, sawdust, clay,
-
Hot selling in Brazil !!! rotary dryer for coal powder, sand, sawdust, clay,
-
2011 Hot selling in Philippine !!! rotary dryer for coal powder, sand, sawdust, clay,
-
2011 Hot selling in South africa !!! powder rotary dryer , p
-
2011 Hot selling in RUSSIA !!! rotary drier for coal powder, sand, sawdust, clay,
Product Details
Place of Origin | Henan, China | Brand Name | yufeng | |
Model Number | as parameters | Condition | New | |
After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
High effiecient rotary drum dryer,slurry dryer specifications
The Rotary dryer made by our company is mainly used in building materials, metallurgy, chemical plant, cement plant for drying
Rotary Dryer is suitable for the drying. The dryer adopts the hot wind from burning kiln to eject directly as the method of heating
up. According to the physical characteristic, the inner of the container sets the second granulating area of material. At the time
of material entering into the body and drying, it carries through the second granulation, which increases the intensity and output
of grain. In the container, multi-angle upright board is reasonable distributed so that equal distribution of grain and the big heated area make material and kiln
gas of high-temperature exchange sufficiently to make good drying effect1. Hot-wind ejection equipment that specially designed can stabilize the balance of working temperature sufficiently to reduce the loss
of nutrient. It is especially adapted to the urea products .
Working principle of the rotary dryer:
Material to be dried enters the dryer, and as the dryer rotates, the material is lifted up by a series of internal fins lining the inner
wall of the dryer. When the material gets high enough to roll back off the fins, it falls back down to the bottom of the dryer, passing
through the hot gas stream as it falls. This gas stream can either be moving toward the discharge end from the feed end (known
as co-current flow), or toward the feed end from the discharge end (known as counter-current flow). The gas stream can be made up of a mixture of air and combustion gases from a burner, in which case the dryer is
called a direct heated dryer. Alternatively, the gas stream may consist of air or another (sometimes inert) gas that is preheated.
When the gas stream is preheated by some means where burner combustion gases do not enter the dryer, the dryer known as
an indirect-heated type. Often, indirect heated dryers are used when product contamination is a concern.
Specific-ations(m) | Capacity(t/h) | Main motor | Main gear box | Weight(t) | ||
Power(kw) | Model | Model | Speed reduction ratio | |||
Ø1.2*10 | 2.5 | 7.5 | Y160M-R3 | ZL50-16-I | ----- | 13.5 |
Ø1.5*12 | 3.3-4.9 | 10 | Y160L-6-B3 | JZQ500-III-2F | ----- | 18.9 |
Ø1.5*15 | 4-6 | 18.5 | Y200L1-6 | JZQ500-III-2F | ----- | 21 |
Ø1.8*12 | 4-6 | 18.5 | Y160L-6 | ZQ50-16II-2 | 16.46 | 22.83 |
Ø2.2*12 | 7-12 | 18.5 | Y200L7-6 | JZQ650-III | 31.5 | 37.6 |
Ø2.2*14 | 7-12 | 22 | Y200L7-6 | JZQ650-III | 31.5 | 40 |
Ø2.2*16 | 12 | 30 | Y225M-6 | JZQ750-III | 31.5 | 45 |
Ø2.4*14 | 12 | 30 | Y250M-6 | JZQ750-III | 31.5 | 51 |
Ø2.4*18 | 10-13 | 37 | Y250M-6 | ZL85-13-I | 27.16 | 54 |
Ø2.4*20 | 10-14 | 37 | Y250N-6 | ZL85-13-I | 27.16 | 54.14 |
Ø3*20 | 25 | 55 | Y250M-4 | ZL100-16-I | 41.52 | 78 |
Ø3*25 | 32-36 | 75 | YR280M-4 | ZL100-16-I | 41.52 | 104.9 |
