Specifications
Rotary Kiln1.calcine and dry
2.various models suitable for your capacity
3.direct manufacturer
4.more than 60x experience
As the main equipment in both of the cement clinker dry and wet process production lines, this cement rotary kiln is widely used in metallurgy field, chemical industry, building refractory material sector, environmental protection field, and so on. It mainly consists of cylinder body, supporting device, supporting device with catch wheel, driving device, movable kiln head, sealing equipment of the kiln end, coal spraying pipe, etc.
6.2×87m Rotary Kiln
Technical Performance
Specification
Output: 12000t/d dry process cement production line I
nclination: 3.5%
Amount of supports: 3
Rotating speed: main driving: 0.45~4.5r/min;
auxiliary driving: 8.5r/h
Sealing mode: sheet steel for sealing kiln head and end
Cooling of kiln head: air cooling Cooling of Ⅰ, Ⅱ thrust roller belts: air cooling
Driving mode: bilateral driving; main driving motor: 1050×2 KW.
Main Components
1. Cooling tube for kiln head
2. Air cooler for Ⅰand Ⅱ thrust roller belt
3. 3 supporting devices
4. Cast alloy steel supporting rollers are designed with solid construction
5. Cone thrust rollers are made of cast alloy steel, and they have undergone normalizing treatment. The weight of double thrust roller is 5250kg
Note: parameters in the form are only for reference, and specific ones should refer to the contract.
