Specifications
Vibrating feeder1.Convey large bulk material
2.used to match the crushing and sieving equipments
3direct manufacturer
Vibrating feeder
For the purpose of not affecting the performance, intercept mineral board shall not be fixed to the plate on the tank. To enable a smooth discharge silo, the inclination of silo posterior is best between 55-65 degrees.
structure
Our company Vibrating Feeder is newly designed for uniformly conveying bulk materials to coarse and intermediate crushing and screening machine.It adopts double eccentric shaft vibration exciter machine ‘s structural characteristics to ensure that the equipment can withstand the impact of falling bulk materials, improve feeding capacity. That has been widely used in electric power, coal, building materials, chemical, mining, metallurgy, light industry.
note
Vibrating feeder is mainly composed of a vibration machine frame, vibration motor, spring, bearing seat and a wear resistant lining board.
Technical Parameter
| Model | Max. feeding (mm) | Pocessing capacity(t/h) | Motor power(kw) | Obliquity of material trough | Total weight (kg) | Trough size (mm) | Dimensions (L*W*H)(mm) |
| GZD-850*3000 | 400 | 120 | 3.7*2 | 5 | 3607 | 850*3000 | 3110*1800*1600 |
| GZD-1000*3600 | 500 | 150 | 5.5*2 | 5 | 3895 | 1000*3600 | 3850*1950*1630 |
| GZD-1100*4200 | 580 | 240 | 5.5*2 | 5 | 4170 | 1100*4200 | 4400*2050*1660 |
| GZD-1100*4900 | 580 | 280 | 7.5*2 | 5 | 4520 | 4900*1100 | 5200*2050*1700 |
| GZD-1300*4900 | 650 | 450 | 11*2 | 5 | 5200 | 4900*1300 | 5200*2350*1750 |
| ZSW-380*95 | 500 | 96-160 | 11 | 0 | 4082 | 3800*960 | 3920*1640*1320 |
| ZSW-490*110 | 630 | 120-280 | 15 | 0 | 5352 | 4900*1100 | 4980*1830*1320 |
| ZSW-600*130 | 750 | 400-560 | 22 | 0 | 7800 | 6000*1300 | 6082*2580*2083 |
