Perfect!!! HZS50concrete Admixture Mixing Plant

Name: Perfect!!! HZS50concrete Admixture Mixing Plant
Brand: shandong lianchuang
SKU: 139855009

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

shandong lianchuang

Shandong Lianchuang Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name shandong lianchuang

Model Number hzs50

Specifications

1.Excellent mixing performance
2.High reliability
3.Easy operation
4.Reasonable price
5.ISO certify

HZS50concrete admixture mixing plant

Technical Parameters

Model		HZS50
Production capacity: m³/h		50
Mixer		JS1000
Scale measure/preciseness	Aggregate:kg	1000±2% (Belt discharge)
		2000±2% (Cylinder operated discharge)
	Sand: kg	1000±2% (Belt discharge)
		2000±2% (Cylinder operated discharge)
	fly ash :kg	200±1kgchoice according to request of user
	Cement: kg	500±1%
	Water :kg	400±1%
	Additive: kg	50±1%
Aggregate feed bins and volume(default)		3x6m³
Note: Bins compartments, volume and installation can be adjusted according to customers requests
Aggregate conveyor		Groove belt feeder or bucket feeder, can be adjusted according to customers requests
Filler scale(default)		1 unit
Note: Quantity of filler scales can be adjusted according to customers requests
Full automatic control mode(default)		One independent control system for each plant
Monitoring system(default)(		None
Outer packaging: (default)		None
Storage silos		Capacity, quantity and auxiliary are supplied upon customers requestment.
Assembly power		76 kW
External dimension (LWH)		According to the model of disposition and layout

Other model

HZS25,HZS40,HZS50,HZS75

HLS60,HLS90,HLS120,HS180

Model	HZS25	HZS40	HZS50	HZS75
Max theory productivity(m³/h)	25	35	50	75
Mixer	JS500	JS750	JS1000	JS1500
Storage bucket capacity(m³)	3×3	3×4	3×7	3×8(12)
Maximum size of aggregate(mm)	60/80	60/80	60/80	60/80
Discharge height(m)	1.6-3.8	1.6-3.8	1.6-3.8	1.6-3.8
Charge height(m)	2.7	2.7	2.9	2.9
Aggregate measuring accuracy(%)	±2	±2	±2	±2
Cement measuring accuracy(%)	±1	±1	±1	±1
Fly ash measuring accuracy(%)	±1	±1	±1	±1
water measuring accuracy(%)	±1	±1	±1	±1
additive measuring accuracy(%)	±1	±1	±1	±1
Power(kw)	35	50	60	85
Total weight(kg)	14000	18000	25000	35000
