Specifications
1.Rich expertise2.Wide storing capacity range
3.ISO9001:2008&CE
4.The silo body uses Galvanizing steel
5.Operated easil
2014 hot!!! 100ton cement silo for sale
Application of cement silo
It is suitable for storing bulk materials such as grains, cement, powder and fly ash. Material level system is installed in the tanks, which can show the position and quantity of the materials. The hole device can clear up hard materials from long sediment. The materials can be sent to all the positions with the combination of cement bin and screw conveyer pump. Easy installation with its characteristics of safety and reliability makes it an ideal cement bin for the concrete mixing plant.
Manufactured Technology of Cement Silo
The parts of the cement silos are manufactured by special laser cutting and drilling technologies and
they are implemented special surface cleaning procedure. The parts of the cement silos also are
manufactured in sensitive production facilities with special equipments and they are painted with
prime coating and final coating. The parts which are hung on automatic conveyor line , are painted in
special painting cabinets. Then the parts of the cement silos are packed specially suitable for transportation.
Advantages
- With different capacities:50T,100T,150T,200T,etc.
- Customized sizing and layout to specific requirement
- Sub-structure, easy transportation, installation fast, level display, with positive and negative regulator,Green filter
- Put in bulk powder (cement or fly ash), waterproof and moisture, easy to use and reduce costs , the top of cement silo with green filter, used to reduce dust leakage.
- Equipped with a safety valve at the top of cement silo, cement silo used to balance the pressure difference between inside and outside. Upper and lower parts of the cement silo is equipped with display materials, can monitor the number of cement materials warehouse. With gas in the lower part of broken cement storage devices, to ensure smooth unloading.
- Cement bin is cylinder and supporting structure. The superior part has dust removing device to avoid leakage of dust; and the inferior part is equipped with arch breaker to avoid powder caking and make discharging smooth, and bin level sensing device to master usage of material in the bin at any time.
- Cement bin generally adopts bulk cement conveying truck to send powder in the bin by pneumatic conveying; according different structures of cement bin, there are two kinds of discharging: the first is the inferior part is connected with screw conveyer and screw conveyer send powders into powder measure; the second is to adopt pneumatic conveying (to special cement bin).
The Main Parameters of Cement silo
Model |
100T |
Silo Diameter (A) |
3,000mm |
Silo Body Height (H1) |
9,810mm |
Silo Cone Height (H2) |
2,579mm |
Silo Height (H3) |
19,789mm |
Total Height (H4) (including handrails) |
20,902mm |
Discharging Height (H5) |
7,400mm |
Total Weight |
8T |
Material |
Q235 |
Steel Thickness (from Cone to Top) |
6-6-5-4-3mm |
Accessories |
Dust Collector, Handrails, Inside& Outside Ladders, Inlet Tube, Butterfly Valve, Support Legs, Arch Breaking |
Serial number |
Spec |
Diameter mm |
Leg height mm |
Total height mm |
Theoretical capacity t |
1 |
SNC60 |
2,800 |
4,000 (6,000) |
8,130 |
60 |
2 |
SNC100 |
2,800 |
4,000 (6,000) |
12,000 |
100 |
3 |
SNC150 |
3,900 |
4,000 (6,000) |
12,736 |
150 |
4 |
SNC200 |
4,500 |
4,000 (6,000) |
13,000 |
200 |
5 |
SNC500 |
7,000 |
4,000 (6,000) |
17,500 |
500 |
transportation
After-Sales Service
1.Spare parts will be delivered as you need.
2.Engineers will go to clients’ site for guiding the installation and test-running;
3.Warranty period: 12 months since the installation and commisioning;
4.Service team will follow every placed order regularly till warranty period finished
Success Case
So far as now, our concrete mixers are sold in Mongolia, Uzbekistan, Kazakhstan, Congo, Nigeria, Singapore, Ghana, Russia, Chile, Philippines, Kenya, Armenia,
Our stationary concrete batching plants are sold in Nigeria, Congo, Chile, Philippines, Mongolia, Russia, Kazakhstan, Uzbekistan, Russia, Nigeria, Armenia, etc..
Our mobile concrete batching plants are sold in Mongolia, Russia, Kazakhstan, Uzbekistan, Pakistan, Philippines, etc.
What's more, they have received praise with good quality and excellent after-sale service.
You are always welcomed to visit our company and workshop!!
Our Service
As a professional exporter, our target is to serve worldwide clients with high-quality products, great reliability, devoted responsibility, professional services and honorable credibility to meet customers' requirements in all aspects. Offer skillful after-sale-service specialists are available for all customers at 7/24 hours every week.
