quinoa seed cleaning processing machine
Introduction of quinoa seed cleaning processing machine
The standard design of the machine is provided with both pre- and after suction units.
Quick screen changing from pre-cleaning into fine cleaning by the operator serves to optimize the cleaning tasks.
The 5X series bean cleaner is a very competitive machine, both as regards price and capacity as well as function and operation.
The technology of the machine is thoroughly tested, which can be documented by many references all over the world.
Advantage of quinoa seed cleaning processing machine
- Easy and quick operation and screen changing
- The screen boxes are made of wear resistant plywood, which is approved for food
- Screen cleaning with special rubber balls
- Built-in light.
- Durable surface of the machine owing to high-quality powder lacquering
Specification of quinoa seed cleaning processing machine
Model |
5X-5 |
5X-12 |
Dimension(L×W×H) |
3200×1920×3600 mm |
3790×1940×4060 mm |
Overall weight |
3250 kg |
3600 kg |
Rated capacity |
5 t/h |
12 t/h |
Overall air volume |
8200 m3 |
12520 m3 |
External air blower |
4-72N0-6A, 7.5 kW |
4-79N0-6A, 5.5kw |
Vibration sieve motor(gear motor) |
2.2 kW |
2.2 kW |
Back lifting system motor |
3.0 kW |
3.0 kW |
Feeding motor |
1.5 kW |
0.75kw |
Total Power |
6.7 kW |
11.45kw |
Air Blower Type |
centrifuge air blower |
|
Top air blower Rotary speed |
4-79NO6A,1400 r/min |
|
Back lifting air blower Rotary speed |
100~1000 r/min |
|
Screen Type |
piercing screen |
|
Screen Dimension (L×W) |
800×1250 mm |
|
Frequency |
300(80~400) times/min |
|
Amplitude |
30 mm |
|
Layers and number |
4 layers,7 pieces |
5 layers,15 pieces |
Screen number and type | ||
level 1 |
1 piece round hole |
3 pieces slot hole |
level 2 |
2 pieces slot hole |
3 pieces slot hole |
level 3 |
2 pieces slot hole |
3 pieces slot hole |
level 4 |
2 pieces slot hole |
3 pieces slot hole |
level 5 |
null |
3 pieces slot hole |
Photos of quinoa seed cleaning processing machine
Other machine models you may interested.
5XQS-5 model Destoner --- widely used in all type grain to remove stones, glass and other hevey impurity.
5XZ-6 model Gravity Separator --- used to remove bad, moldy, immature, eaten seeds, fits for all types grain application
1 Ton/hour quina seed processing plant built in Australia, click to know more!
2.Q Can you offer machine working video?
A Yes, no problem. Please send me inquiry or contact me by joyce at ( or j at ). I will send machine video to you.
A Of course. Up to now, we sold machine over 100 countries. We load containers every week. Express delivery, air shipping, sea shipping, are all we farmiliar transportation methods.
4.Q What about after sales service? Do you help to install the machines?
A We offer user manual book, operation guidance DVD. We also can send engineers offer on site installation, test running, and training. Clients` satisfiaction is our aim.
ANY FURTHER QUESTIONS, FEEL FREE TO CONTACT ME.
