Barley, Mung Bean, Maize Seed Cleaner

Name: Barley, Mung Bean, Maize Seed Cleaner
Brand: SYNMEC
SKU: 139842083

US$ 14,500 - 17,000 MOQ: 1 Set

Key Specifications

Type:

grain cleaning machinery

Use:

grain seed cleaning

Certification:

ISO,TUV,SGS

Shijiazhuang Synmec International Trading Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xingang

Delivery Detail:

Delivery time depends on order quantity.

Type grain cleaning machinery

Use grain seed cleaning

Certification ISO,TUV,SGS

Place of Origin Hebei, China

Brand Name SYNMEC

Model Number 5X-5

Condition New

After-sales Service Provided Engineers available to service machinery overseas

barley, mung bean, maize seed cleaner

Product Description

Introduction of barley, mung bean, maize seed cleaner

The standard design of the machine is provided with both pre- and after suction units.

Quick screen changing from pre-cleaning into fine cleaning by the operator serves to optimize the cleaning tasks.

The 5X series bean cleaner is a very competitive machine, both as regards price and capacity as well as function and operation.

The technology of the machine is thoroughly tested, which can be documented by many references all over the world.

Advantage of barley, mung bean, maize seed cleaner

- Easy and quick operation and screen changing

- The screen boxes are made of wear resistant plywood, which is approved for food

- Screen cleaning with special rubber balls

- Built-in light.

- Durable surface of the machine owing to high-quality powder lacquering

Specification of barley, mung bean, maize seed cleaner

Model	5X-5	5X-12
Dimension(L×W×H)	3200×1920×3600 mm	3790×1940×4060 mm
Overall weight	3250 kg	3600 kg
Rated capacity	5 t/h	12 t/h
Overall air volume	8200 m3	12520 m3
External air blower	4-72N0-6A, 7.5 kW	4-79N0-6A, 5.5kw
Vibration sieve motor(gear motor)	2.2 kW	2.2 kW
Back lifting system motor	3.0 kW	3.0 kW
Feeding motor	1.5 kW	0.75kw
Total Power	6.7 kW	11.45kw
Air Blower Type	centrifuge air blower
Top air blower Rotary speed	4-79NO6A,1400 r/min
Back lifting air blower Rotary speed	100~1000 r/min
Screen Type	piercing screen
Screen Dimension (L×W)	800×1250 mm
Frequency	300(80~400) times/min
Amplitude	30 mm
Layers and number	4 layers,7 pieces	5 layers,15 pieces
Screen number and type
level 1	1 piece round hole	3 pieces slot hole
level 2	2 pieces slot hole	3 pieces slot hole
level 3	2 pieces slot hole	3 pieces slot hole
level 4	2 pieces slot hole	3 pieces slot hole
level 5	null	3 pieces slot hole
