Continuous Biodiesel Production Machine, Biodiesel Making From Palm Oil, Biodiesel Making from Used Cooking Oil
1)Biodiesel manufacturer price
2)Professional exporter
3)Stable Quality with international starndard
4)Stable supply
1. The raw material biodiesel production machine can use.
Biodiesel refers to a vegetable oil - or animal fat-based diesel fuel consisting of long chain alkyl (methyl, ethyl, or propyl esters. Biodiesel is typically made by chemically reacting lipids (e.g., vegetable oil, animal fat) with an alcoholproducing fatty acid esters.
Biodiesel is meant to be used in standard diesel engines and is thus distinct from the vegetable and
waste oils used to fuel converteddiesel engines. Biodiesel can be used alone, or blended with petrodiesel
in any proportions. Biodiesel blends can also be used asheating oil.
NO. | Raw material | Note |
1 | Slaughterhouse scraps | From slaughter house |
2 | illegal cooking oil | Waste cooking oil |
3 | Fatty Acid & Acid Oil from plant refinery | For example the bean & peanut etc..... |
4 | Plam oil & Plant oil and so on...... | soybean oil, rapeseed oil, sunflower oil |
The machine is same, just processing and catalyst is different . Our engineer will training you as your raw material use. | ||
2.Scale of Biodiesl Production Machine Construction
- Raw material receiving ~ 300t/d
- Raw material storage scale ~20000t
- Pre-treatment workshop 10~300t /d
- Synthetic refining workshop 10~300t /d
3. Biodiesel which produced by our biodiesel production machine parameter
NO. | Item | Unit | Parameter |
1 | density (20°C) | (kg/square meter) | 0.82-0.9 |
2 | KineSulfur acidmatic viscosity(40°C) | (m/square meter) | 1.9-6.0 |
3 | Closed flash point | °C | ≥130 |
4 | Freezing point | °C | ≥0 |
5 | Sulfur content(The mass fraction) | m/m% | 0.02 |
6 | SteamCetane numbered tailings carbon residue(The mass fraction) | % | ≤0.3 |
7 | Sulfur acid ash(The mass fraction) | % | ≤0.020 |
8 | Water content(The mass fraction) | % | ≤0.05 |
9 | Mechanical impurities |
| none |
10 | Copper corrosion(50°C,3h) | grade | ≤1 |
11 | Cetane number |
| ≥49 |
12 | Oxygen stability(110°C) | hour | ≥6.0 |
13 | Acid value/(mGkoH/g) |
| ≤0.80 |
14 | Free glycerol contents (The mass fraction) | % | ≤0.020 |
15 | Total glycerin content (The mass fraction) | % | ≤0.240 |
16 | Recovery temperature | °C | ≤360 |
4. Cover area of the biodiesel production machine:
NO. | Model | Cover area | Note |
1 | BD-5 | 80 square meters |
|
2 | BD-10 | 120 square meters | |
3 | BD-20 | 150 square meters | |
4 | BD-50 | 200 square meters | |
5 | BD-100 | 300 square meters |
5. How many workers need to operate biodiesel production machine:
NO. | Model | Workers amount |
1 | BD-5 | 3 |
2 | BD-10 | 5 |
3 | BD-20 | 6-7 |
4 | BD-50 | 10 |
5 | BD-100 | 15 |
Advantage of Kingdo Biodiesel Production Machine
- Engine is starting at low temperature(-10C).
- It not belongs to dangerous cargo, so it’s easy to transport.
- There is less sulfur and aromatic alkyl in biodiesel, so it's less harmful to human and environment.
- As a kind of renewable energy sources, the biodiesel will not finised.
- The supply of biodiesel is not controlled by OPEC, it’s benefit to the stability of international petroleum market.
1. Preprocessing section of bio-oil: when heated to 65-70°C, bio-oil is leached to remove impurities.
2. Drying section: bio-oil without impurities is dehydrated and dried.
3. First esterification reaction: adding bio-oil dehydrated to methanol including 3% sulfuric acid, first esterification reaction starts, and it will take 1.5—2.5 hours.
4. Second esterification reaction: this esterification reaction will take 9—12 hours.
5. Vacuum drying section: Second esterification reactants are dried with vacuum, removing moisture, reducing
water content below 3%.
6. Distillation section: with vacuum state, second esterification reactants after vacuum drying section are
heated to 220C, biodiesel forms by steaming. Then cooling biodiesel to be liquid, the liquid biodiesel is just
finished biodiesel.
7. Methanol fine-distillation: after biodiesel is isolated, the remaining methanol liquid is distilled
to form methanol. Methanol cooled can be reused.Bio-oil can be plant oil, animal oil or high acid-value waste oil.
Biodiesel Production Flow Chart
Henan Hi-tech Kingdo Industrial Company Ltd. headquartered in Zhengzhou National Hi-Tech Industrial Development Zone, Henan province. Kingdo owns three subsidiaries and a machinery manufacturing plant, and it is a comprehensive industrial company on scientific research, manufacturing and sales,and covering oil engineering, biodiesel, biogas, grain processing, biotechnology, water treatment equipment and international trade business.
To adapt to the market change at home and abroad, and the significant features of scale merits regarded as the development trend in oil industry, Henan Kingdo Industrial Co., Ltd, has sucessfully developed the fuel used biodiesel project by taking unfit human consumption and waste animal and vegetables oil as raw meterials, which extends the productivity and reduces the cost. It is the green health concept that guiding the enterprise brand benefit and temporizing to the requirement of market development.
Kingdo always put the interests of customers and products quality to the first level, we keep on improving customer satisfaction as the goal of our unremitting efforts. We will be commitment to provide high quality equipments with perfect site services and after-sales service. Now the specific commitments are as follows:
- Ensure to timely provide complete sets of equipment and accessories
- Ensure that one-time installation debugging acceptance
- To provide high quality material with preferential price
- Priority to provide customer our new craftworks and products
- Free training technological operator to ensure the trained staff can operation independently.
- In the installation process, we will appoint a installation supervision staff on the spot
- we will offer an experienced project manager, organize a good installation team for the work of field installation debugging.
- 12 months guarantee on the whole set of equipments we offered, in the warranty period, all because of the quality of products has caused the damage or failure of equipment, suppliers will take the responsibility for the free repair and replacing spare part. Due to the damage caused by the customer, we only charge material costs for repair and replacement. After the receipt of customers notice, we will suggest the method to solve problem within six hours, or send specialist to where the project located to solve the problem.
- After the equipment field assembly and installation, we will be also responsible for the single equipment debugging, online debugging and Feeding trial operation, to ensure that equipments can normal operate in full load conditions. We will provide all kinds of information and records according to the requirements of the bid. The qualified completion files will be provided to customers according to their requirements within one month after acceptance.
Some shipping pictures for the biodiesel production machine
Care, efficient and smile are our customer service principles.
Our customer Services are available 24 hours 7days.
You can rest assured with us.
If you have any inquiry about our company, our products and logistics, please feel free to call or email us any time, any place.
