JP70-P Wall Plastering Machine Used Widely in Kuwait, Malaysia, China

JP70-P Wall Plastering Machine Used Widely in Kuwait, Malaysia, China photo-1
JP70-P Wall Plastering Machine Used Widely in Kuwait, Malaysia, China photo-2
JP70-P Wall Plastering Machine Used Widely in Kuwait, Malaysia, China photo-3
JP70-P Wall Plastering Machine Used Widely in Kuwait, Malaysia, China photo-4
JP70-P Wall Plastering Machine Used Widely in Kuwait, Malaysia, China photo-5
US$ 4,200 - 6,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
plastering, grouting and pumping mortar,fireproof, thermal insulation
Place of Origin:
Zhejiang, China
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI/NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application plastering, grouting and pumping mortar,fireproof, thermal insulation
Place of Origin Zhejiang, China
Brand Name Wengong
Model Number JP70-P wall plastering machine
Dimension(L*W*H) 2040X820X950mm
Weight 275KGS
Certification CE, ISO9001:2008
Warranty 6months
After-sales Service Provided Engineers available to service machinery overseas



Product Description

                                                             JP70-P Wall Plastering Machine

1. JP70-P,JP70-S plastering machine is multi-functional large output plastering machine introduced Italian technology.

2. JP70-P plastering machine has the combined functions of pumping, bonding and plastering. It's suitable for different characteristics dry ready-mixed mortar construction.



3. With modular structure, it's easy to move, dissemble and operate.



4. JP70-P  can spray and pump max height: 30m and distance:50m, max pumpable grain size:8mm.





Old design:



JP70-P wall plastering machine used widely in Kuwait, malaysia, China



New design:



JP70-P wall plastering machine used widely in Kuwait, malaysia, China



Technical parameters of JP70 Mortar plastering machine



Model

JP70-P

JP70-S

Supply power

400V 50Hz

400V 50Hz

Motor power

kw

3.7/4.4

3.7/4.4

Compressor power

kw

2

Maximum grain size

mm

8

8

Output

l/min

50

50

Delivery pressure

bar

30

30

Horizontal delivery distance

m

60

60

Vertical delivery distance

m

30

30

Hopper volume

L

120

120

Net weight

kg

275

275

Dimension (L×W×H)

mm

2040×820×950

2040×820×950





1. JP70-P plastering machine is installed air compressor and motor, the motor and air compressore are both imported from Germany. The quality you can be no worried too much.



JP70-P wall plastering machine used widely in Kuwait, malaysia, China



JP70-P wall plastering machine used widely in Kuwait, malaysia, China



2. you can see the plastering effect with fast speed about 1000-1200m2 per 7hours.



  JP70-P wall plastering machine used widely in Kuwait, malaysia, China



3. JP70-P standard spare parts

JP70-P wall plastering machine used widely in Kuwait, malaysia, China



Company Information



1. our factory and workshop
JP70-P wall plastering machine used widely in Kuwait, malaysia, China

JP70-P wall plastering machine used widely in Kuwait, malaysia, China





2. Our Bamua fair in Shanghai 2012 and 2014

JP70-P wall plastering machine used widely in Kuwait, malaysia, China



JP70-P wall plastering machine used widely in Kuwait, malaysia, China

3. Our contact



JP70-P wall plastering machine used widely in Kuwait, malaysia, China
