Specifications
concrete grout pump>Use hydraulic circuit
>advanced S-control valve
>ISO9001:2008
>10m3/h
Concrete grout pump
1. Application
1.pump or grout the warm lightweight foam insulation cement, mortar and small aggregate concrete;
2.transport or grout refractory, insulation materials (shotcrete);
3.transport or grout the soil in green ecological environment construction (shotcrete);
4. various types of concrete construction, transport fiber reinforced concrete (injection);
5. pressure grouting all types of foundation piles.
2. Features
1. power system using well-known brand motors.
2. double pump dual-circuit hydraulic system is small impact with high reliability.
3. have anti-pump function, be beneficial to remove plugging failure, and it can be the short period of downtime .
4. use advanced S pipe distribution valve automatically compensates for wear gap, good sealing performance.
5.wear-resistant alloy glasses, plates and cutting rings, long service life.
6. long stroke cylinder extends the expected life of the cylinder and piston.
7. optimal design of hopper suction is better performance and higher efficiency.
8. automatic centralized lubrication system ensures the effective operation of the machine lubrication.
9. product of human design makes the operation more convenient, more simple to maintain.
Technical parameters of High-floor cement mortar pump
Model |
-- |
BS12-06-22 |
Theoretical displacement |
m³/h |
12 |
Maximum theoretical working pressure |
Mpa |
6 |
Maximum vertical delivery distance |
m |
80 |
Maximum horizontal delivery distance |
m |
300 |
Maximum grain size |
mm |
20 |
Slump |
mm |
12-23 |
Delivery hose diameter |
mm |
100A/70A |
Cylinder diameter and stroke |
mm |
Φ120×700 |
Piston qty |
piece |
2 |
Hydraulic tank capacity |
mm |
165 |
Feeding height |
mm |
1100 |
Hopper Capacity |
L |
0.30 |
Main motor power |
kw |
22 |
Dimension (L×W×H) |
mm |
4000×1300×1550 |
Weight |
kg |
1800 |
1. concrete mixer pump inside compaction as below:
2. Accessories as below:
1. Concrete mortar pump workshop
Concrete pump worked in Malaysia
