CE,ISO90012008 mini plastering machine 140kgs

Specifications

mini plastering machine
>produce10years,CE
>spray putty &gypsum
>spray distance:0-20m
>110V,220V, 60/50HZ

JP15-1   mini plastering machine



1.JP15-1 model series putty sprayer machine is used for mixing, conveying, spraying different dry mortar, glue mortar, thin layer of mortar, mixed colors mortar, gesso.





2. It's more used to fill frame of door, repairing fire proofing concrete and the thermal system engineering.









Technical parameters



Model	JP15	JP15-1
Discharge capacity	20 L/min	15L/min
Conveyance pressure	20 bar	1.5 bar
Mixing bunker volume	40L	40L
Engine Power	2.2kw	1.5kw
Theoretical conveyance height	40m	30m
Theoretical  horizontal conveyance distance	20m	15m
Weight	145kg	140kg
Dimension	880×590×1138mm	880×590×1200mm





 1.  JP15-1 is installed two piston air compressor which can offer large air output but lower pressure.

 So it's very easy to plaster the sticky material, such as putty. And it's much each easier to plaster gyspum, lime etc.





2. Due to its small size, it's very suitable for light duty plasterin. Max plasterig height is 15m while plastering distance is 20m.
