Specifications
This is one of High Quality Trailer made by Tantri for transport bridge beams and other heavy, long beams and pipes.Chassis :-
Model - TST40-100T
Trailer Weight - 9970Kg. (unladen),
Overall Length - 12595mm, Width - 2440mm, Height - 1840 mm
Main Frame - High Tensile Steel 400x200x12x9mm (main “I” beam), 150x200x9x6mm (“I” beam
bolsters) and 150x75x6mm.
Mudguards - Heavy duty plastic mudguards with mud flaps.
Landing Legs - 80,000 Kg. Static loading capacity.
Brakes - 2 Line pneumatic brake system with RE6 relay emergency valve.
King Pin - 50 mm Dia forged steel King Pin
Lights - LED 24V light system (signal, brake, parking & number plate)
Paints - Shot blasted, epoxy primer coated and top coated with customer preferred colour.
Running Gear :-
Axles - 5 x 16 ton capacity square beam axles
Suspension - Tandem + tridem suspension system (04 + 06 Nos. leaf spring bundles)
Wheels - 18 Nos. 9.00 x 22.5, 10 Holes hub
Tires - 18 Nos. 315/80 x 22.5, 16/18PR (Tubeless tires)
Including :- Options :-
02 Nos. Spare wheel with carriers Additional spare wheel carrier
Rear bumper guards ABS Brake
Safety luminous fittings
