Spring Spindle Breaker of Tengfei Brand for Sale
- Qingdao/Shanghai
- T/T
You May Like
-
Best-selling Spring Type Gyratory Crusher of Tengfei Brand
-
Best-selling Spring Type Gyratory Crusher of Tengfei Brand
-
2013 the Lastest Vibrating Feeder Used for Construction
-
Tengfei-- Circular Vibrating Screen for Sale
-
Hydraulic Simon Cone Crusher for Sale
-
PCL Sand Making Machine With ISO Certificate
Product Details
Condition | New | Type | Cone Crusher | |
Application | Stone crushing | Motor Type | AC Motor | |
Power(W) | 55-280kw | Capacity(t/h) | 15-340t/h | |
Place of Origin | Henan, China | Brand Name | Tengfei | |
Model Number | PYZ-900 | Dimension(L*W*H) | 2692*1640*2350 | |
Weight | 11.2T | Certification | ISO/CE | |
Warranty | 2years | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Spring spindle breaker1.Quality-controol with ISO certificate
2.Well-designed structure
3.High-efficiency
Spring Cone crusher
Suitable to crush various kinds of ores and rocks of medium or above medium hardness. Compared with Jaw Crusher, Spring Cone Crusher is of stable structure, high efficiency, easy adjustment, and economical using etc. The spring safety system of crusher acts as an overloading protection system that allows metals to pass through the crushing e safety system uses dry oil and water as two kinds of sealed formation to make plaster powder and engine oil separatchamber so as not to damage the Cone Crusher. Thed to make sure reliable performance. This type of crushing chamber depends upon the size of feeding and fineness of the crushed product. The standard type (PYB) is applied to medium crushing, the medium type is applied to medium or fine crushing and the short head type is applied to fine crushing,non metalic minerals processing machines. gyratory crusher . spindle breaker
Specifications and parameter of spring cone crusher
Model | Diameter of Bottom End of Conical Crushing Head (mm) | Max Feeding Size (mm) | Adjustable Range of Discharge Opening (mm) | Crushing Capacity | Motor Power | Rev.of Eccentric Shaft | Weight (t) | Overal Dimension (L×W×H) (mm) |
PYB900 | 900 | 115 | 15-50 | 50-90 | 8P-55 | 333 | 11.2 | 2692×1640×2350 |
PYZ900 | 900 | 60 | 5-20 | 20-65 | 8P-55 | 333 | 11.2 | 2692×1640×2350 |
PYD900 | 900 | 50 | 3-13 | 15-50 | 8P-55 | 333 | 11.3 | 2692×1640×2350 |
PYB1200 | 1200 | 145 | 20-50 | 110-168 | 8P-110 | 300 | 24.7 | 2790×1878×2844 |
PYZ1200 | 1200 | 100 | 8-25 | 42-135 | 8P-110 | 300 | 25 | 2790×1878×2844 |
PYD1200 | 1200 | 50 | 3-15 | 18-105 | 8P-110 | 300 | 25.3 | 2790×1878×2844 |
PYB1750 | 1750 | 215 | 25-50 | 280-480 | 8P-160 | 245 | 50.3 | 3910×2894×3809 |
PYZ1750 | 1750 | 185 | 10-30 | 115-320 | 8P-160 | 245 | 50.3 | 3910×2894×3809 |
PYD1750 | 1750 | 85 | 5-13 | 75-230 | 8P-160 | 245 | 50.2 | 3910×2894×3809 |
PYB2200 | 2200 | 300 | 30-60 | 590-1000 | 8P-(260-280) | 220 | 80 | 4622×3302×4470 |
PYZ2200 | 2200 | 230 | 10-30 | 200-580 | 8P-(260-280) | 220 | 80 | 4622×3302×4470 |
PYD2200 | 2200 | 100 | 5-15 | 120-340 | 8P-(260-280) | 220 | 81.4 | 4622×3302×4470 |
