Help CenterGood Price Concrete Mix Car 8cbm Brand New Cement Mixer Truck
Related Products
-
High Quality Brand New Cement Mixer Truck 10m3 Concrete Mixer Truck for SaleUS$ 51,000 - 53,000MOQ: 1 Set -
Factory Supplied Strong Performance LHD/RHD 6m3 Small Concrete Mixer TruckUS$ 42,000 - 46,000MOQ: 1 Set
-
Factory Offered Good Price 8 Cubic Meters Concrete Mixer TruckUS$ 46,000 - 48,000MOQ: 1 Set
-
2015 3m3 Small Truck Mounted Concrete Mixer With Factory PriceUS$ 20,000 - 60,000MOQ: 1 Set
-
ISO Certified 3m3 Mini Concrete Truck Mixer With Factory PriceUS$ 20,000 - 60,000MOQ: 1 Set
Why would our clients choose FOCUS ready mix concrete trucks?
- HINO chassis are available in FOCUS brand new cement mixer truck;
- international famous brand hydraulic drive fits are adopted in our brand new cement mixer truck;
- integral type oil tank, oil cooler and electrical fan are adopted with simple and reliable system; brand new cement mixer truck
- multi-points control system enables the brand new cement mixer truck operation to be easier, safer and more comfortable;
- air pressure water supply system with large capacity water tank.
What are the main features of FOCUS brand new cement mixer truck?
- Oil tank and radiator are imported top brand combination with temperature control switch and vacuum meter while oil change and maintenance are easily realized for our brand new cement mixer truck.
- Pump, motor and reducer in brand new cement mixer truck are all original imported AMERICA static pressure driving system with big driving torque and high efficiency. brand new cement mixer truck
- Imported hose and connector are separately from GERMANY EMB and ITALY MANULI.
- Hose buckling device is totally from GERMANY HYDAC.
- Stirring vat auto-welding improves brand new cement mixer truck production efficiency and makes welding quality finer.
- Tri-axial design and three-section double logarithm helix surface design can ensure concrete speedy feeding and discharge and low surplus rate in our HINO mixer truck .
- Fault indicator for the brand new cement mixer truck can check all welding seams of stirring vat to ensure good welding quality after it’s being welded by auto-welding machine. brand new cement mixer truck
- Truck frame adopts tri-axial lineation machining, and adopts laser check to ensure an accurate installation position.
FOCUS concrete mixer truck technical data
Model |
8m³ |
9m³ |
10m³ |
12m³ |
14³ |
|
|
Truck |
Chassis |
HINO |
HINO |
HINO |
HOWO |
HOWO |
Length(mm) |
8550 |
9200 |
9800 |
10150 |
10150 |
|
Width(mm) |
2490 |
2490 |
2495 |
2496 |
2496 |
|
Height(mm) |
3800 |
3800 |
3830 |
3900 |
3960 |
|
Weight(kg) |
25000 |
25000 |
31000 |
31000 |
31000 |
|
Load weight(kg) |
12600 |
13000 |
15650 |
16370 |
16700 |
|
Max.speed(kg/h) |
75 |
72 |
90 |
90 |
50 |
|
Oil consumption(L/100km) |
32 |
34 |
38 |
38 |
38 |
|
|
Engine |
Engine model |
WD615.69 |
||||
Engine type |
6-cylinder direct injection diesel engine with water cooling |
|||||
Engine power(kg) |
247(2200r/min) |
247(2000r/min) |
||||
Max.torque(N.M) |
1250(1600r/min) |
|||||
|
Working device |
Drum volume(m³) |
12.8 |
14.7 |
17.05 |
19.65 |
20.1 |
Mixing volume(m³) |
8 |
9 |
10 |
12 |
14 |
|
