High Precision Fe-based Nanocrystalline Alloy

High Precision Fe-based Nanocrystalline Alloy thumbnail-1
High Precision Fe-based Nanocrystalline Alloy photo-1
US$ 1 - 100 MOQ: 300 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
Bidragon
Model Number:
Fe-based amorphous alloys
Contact Supplier Request Quote Chat Now
Beijing Double Dragon International Industrial & Mining Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China main port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Beijing, China
Brand Name Bidragon
Model Number Fe-based amorphous alloys
Type Soft
Composite Ferrite Magnet
Shape Strip
Application Industrial Magnet

Specifications

high precision Fe-based Nanocrystalline alloy
1.High saturate induction
2.Improve device efficiency
3.low coercivity
4.CE

  high precision Fe-based Nanocrystalline alloy Physical performance



saturated magnetic induction density Bs

1.56T

Hardness Hv

960

Curie temperature

410°C

Density d

7.18g/cm3

crystallization temperature

550°C

electrical resistivity r

130mW-cm

Saturated magnetic coefficient of dilatation

27×10-6

Continuous working temperature scope

-55-130oC





















magnetic performance





Item

transverse magnetic field annealing

No magnetic field annealing

longitudinal magnetic field annealing

Max magnetic permeability



>2x104

>20´104

>25´104

saturation magnetic induction intensity



1.5 T

1.5 T

1.5 T

residual magnetic flux density

<0.5 T

0.6-1.0 T

1.2 T

coactivity

<4A/m

<6 A/m

<2.5A/m

Wastage (50Hz,1.4T)

<0.2W/kg

<0.13W/kg

<0.25W/kg

Wastage(400Hz, 1.2T)

<1.8W/kg

<1.25W/kg

<2W/kg

Wastage (8kHz, 1.0T)

<80W/kg

<60W/kg

<100W/kg

Wastage (-55°C–125°C)

<15%

<15%

<15%

Wastage (120°C´200 hours)

<15%

<15%

<15%





amorphous alloys Specification





model

Width  mm

thickness mm

RF1-0100

10±0.5

28±2

RF1-0200

20±1

28±2

RF1-0250

25±1

28±2

RF1-0300

30±1

28±2

RF1-0400

40±1

28±2

RF1-0500

50±1

28±2

RF1-1000

100±1

28±2

RF1-1500

150±1

28±2

RF1-1700

170±1

28±2

RF1-2200

220±1

28±2





curve



high precision Fe-based Nanocrystalline alloy



high precision Fe-based Nanocrystalline alloy







For more detailed information please feel free to contact with Yolanda,Skype: bidragon2017
