Ductile iron pipe pricing
Ductile cast iron is a kind alloy of iron, carbon and silicon, in which graphitc exists in the type of spherical,generally the size of graphite is 6-7 class, and spheriedization grade of the pipe should be controlled 1~3 class(spheroidization rate is not below 80%).
Thus after spheriodization, ductile cast iron possesses the nature of iron as weel as the characteristics of steel.
After Annealing, its microstructure contains ferrite and a little pearlite possessing excellent mechanical properties.
| Item Name | Carried Standard | Application | ||
| High Quality Hot Sale Ductile Iron Pipe Pricing From Anyang |
GB1348-88 | Machinery manufacturing, glass curtain wall, marble wall of dry hanging, ship manufacturing, goods stents, steel structure engineering, furniture manufaturing, medical equipment, agricultural and chemical machinery, autoparts, pressure pipes and fittings, automotive applications, buildings, roads, valve manufacturing,etc. | ||
| DN(mm) | DE(mm) | THICKNESS OF WALL(mm) |
WEIGHT OF SOCKET(kg) |
TOTAL WEIGHT(kg) | ||||
| K8 | K9 | K10 | 3.4 | K8 | K9 | K10 | ||
| 80 | 98 | 6.0 | 6.0 | 6.0 | 4.3 | 77.0 | 77.0 | 77.0 |
| 100 | 118 | 6.0 | 6.0 | 6.0 | 5.7 | 93.7 | 95.0 | 95.0 |
| 125 | 144 | 6.0 | 6.0 | 6.0 | 7.1 | 119.0 | 119.0 | 121.0 |
| 150 | 170 | 6.0 | 6.O | 6.0 | 10.3 | 138.0 | 144.0 | 144.0 |
| 200 | 222 | 6.0 | 6.3 | 6.4 | 18.9 | 183.0 | 194.0 | 194.0 |
| 300 | 326 | 6.4 | 7.2 | 8.0 | 23.7 | 290.0 | 323.0 | 357.0 |
| 350 | 378 | 6.8 | 7.7 | 8.5 | 29.5 | 359.0 | 403.0 | 441.0 |
| 400 | 429 | 7,2 | 8.1 | 9.0 | 38.3 | 433.0 | 482.0 | 532.0 |
| 450 | 480 | 7.6 | 8.6 | 9.5 | 42.8 | 515.0 | 577.0 | 632.0 |
| 500 | 532 | 8.0 | 9.0 | 10.0 | 59.3 | 600.0 | 669.0 | 736.0 |
| 600 | 635 | 8.8 | 9.9 | 11.0 | 79.1 | 791.0 | 882.0 | 971.0 |
| 700 | 738 | 9.6 | 10.8 | 12.0 | 102.6 | 1009.0 | 1123.0 | 1237.0 |
| 800 | 842 | 10.4 | 11.7 | 13.0 | 129 | 1255.0 | 1394.0 | 1537.0 |
| 900 | 945 | 11.2 | 12.6 | 14.0 | 161.3 | 1521.0 | 1690.0 | 1863.0 |
| 1000 | 1048 | 12.0 | 13.5 | 15.0 | 237.7 | 1811.0 | 2017.0 | 2221.0 |
Anyang Jin Chao yang Materials Co., Ltd has been in the steel selling and exporting market for many years.
Our rich experiences makes us not only providing the exacty product you need but also providing kinds of solutions solving the problems you may confronting in your work or projects.
Mian Products: Ship plate, boiler and pressure vessel steel, corten steel.HR,CR coil/sheet/plate
Events of Jin Chao Yang:
1. Anyang Jin Chao Yang Materials Co., Ltd was established in 2009.
2. With more than 10staff, Anyang Jin Chao Yang Materials Co., Ltd began to expand the Indian market in 2010 and made a sales volume of 30,000tons.
3. With more than 20staff, Anyang Jin Chao Yang Materials Co., Ltd moved to a new office in 2011.At the same year, the markets in Pakistan, mainly the pressure Vessel Steel plate, in Russia and in Africa,were developed with a sales volume of 55,000tons
4.In 2012, the sales volume were more than 70,000tons
5. The domestic trade company, Henan Youjin Commerce Co., Ltd, under Anyang Jin Chao Yang Materials Co., Ltd, made a sales volume of 9,000tons in 2012 and 27,000tons in 2013.
6. In 2013, the headquarter, Henan Runke Imp.&Exp. Trading Co., Ltd, was established.
............
Q1: How long is your delivery time?
A1: The fastest delivery time is 7days.Generally the delivery time is 20-30dyas.
Q2: What’s your MOQ (Minimum Order Quantity) ?
A2: steel plates: if we have stocks of what do you need, the MOQ will be 1 ton. If we don’t have stocks, we will quote you according to the specific situation such as the specific materials, steel mills’ order requirements and so on. The MOQ will be 50 tons generally in this situation.
Q3: Whether your company can send supporter for a long time or not?
A3: Temporarily we don't have offices in foreign countries. We supply one-year’s free service. Beyond one year you should supply the fare, accommodation cost and technical service fee for the service.
Service
Any question, feel freely to contact us.
Cathy Wang
Email:Cathy(at)
TM:CN1500419683
SKYPE: live:cathy_2931
Tel:+86-371-89918526| Fax:+86-371-53319052
