Steel Wire ( Hot Sale !!!) Manafacture

Name: Steel Wire ( Hot Sale !!!) Manafacture
Brand: YuXiang
SKU: 139806293
Availability: InStock

US$ 700 - 1,500 MOQ: 5 Tons

Key Specifications

Steel Grade:

carbon steel

Standard:

AISI, ASTM, BS, DIN, GB, JIS

Wire Gauge:

0.1-13mm

Nantong Yuxiang Metal Products Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Nantong or shanghai

Delivery Detail:

Delivery time depends on order quantity.

Steel Grade carbon steel

Standard AISI, ASTM, BS, DIN, GB, JIS

Wire Gauge 0.1-13mm

Place of Origin Jiangsu, China

Type Spring

Application Other, steel wire

Alloy Or Not Non-alloy

Special Use Cold Heading Steel

Brand Name YuXiang

Specifications

ISO 9001 certified custom manufacturer of steel wire from 0.15MM to 12MM for consumer, commercial & industrial application

High Carbon Spring Steel Wire

1.Diameter range:0.1-13mm
2.Main application:making spring,mattress,wire rope.

3.Standard:GB4357,DIN17223,JIS G 3521

Standard:DIN17223:

High Carbon Spring Steel Wire
wire diameter(mm)	Tensile Strength(N/mm² )
wire diameter(mm)	Grade A	Grade B	Grade C
0.30		2370-2650
0.40		2270-2550
0.50		2200-2470
0.60		2140-2400
0.70		2090-2350
0.80		2050-2300
1.00	1720-1970	1980-2220
1.20	1670-1910	1920-2160
1.40	1620-1860	1870-2100
1.60	1590-1820	1830-2050
1.80	1500-1780	1790-2010
2.00	1520-1750	1760-1970	1980-2200
3.00	1410-1620	1630-1830	1840-2040
4.00	1320-1520	1530-1730	1740-1930
5.00	1260-1450	1460-1650	1660-1840
6.00	1210-1390	1400-1580	1590-1770
7.00	1160-1340	1350-1530	1540-1710
8.00	1120-1300	1310-1480	1490-1660
9.00	1090-1260	1270-1440	1450-1610
10.00	1060-1230	1240-1400	1410-1570
11.00		1210-1370	1380-1530
12.00		1180-1340	1350-1500
13.00		1160-1310	1320-1470
