D2.0m*L3.5m Pneumatic Ship Dock Rubber Fender

Name: D2.0m*L3.5m Pneumatic Ship Dock Rubber Fender
Brand: Florescence
SKU: 139757007
Availability: InStock

US$ 200 - 2,000 MOQ: 2 Pieces

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Florescence

Model Number:

D2.0m*L3.5m

Qingdao Florescence Rubber Products Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Florescence

Model Number D2.0m*L3.5m

Specifications

dock rubber fenders
1.absorb more energy
2.high shock absorption
3.CCS&BV
4.ISO17357

dock rubber fender

1.Material: natural rubber, rubber-dipped Nylon cord fabric.

2. Certificates: CCS, GL, BV.etc.

Rubber Fender Features: · High energy absorption and low reaction force and surface pressure

· No decline in the rate of energy absorption when obliquely compressed, under normal circumstances, and uniform

·surface pressure for any contact area.

· Low reaction force to prevent damage from repeated impacts against the hull of ship, quay, jetty or mooring rope.

· Ability to float and thus rise and fall with the ebb and flow of tides and the movements of a ship.

· High standard of uniform quality in compression performance with no deterioration of the rubber.

· Easy installation.

Technical parameters of yokohama fender for ship :

Size	Initial Internal Pressure 0.05MPa		Weight ±10%	Initial Internal Pressure 0.08MPa		Weight ±10%
D*L(mm)	R(KN)	GEA(KJ)	Kg	R(KN)	GEA(KJ)	Kg
500*1000	64	6	25	83	8	25
600*1000	74	8	32	96	11	32
700*1500	137	17	50	178	24	50
1000*1500	182	32	80	235	44	80
1000*2000	257	45	100	335	63	125
1200*2000	297	63	120	386	86	165
1350*2500	427	102	165	554	140	226
1500*3000	597	153	315	751	211	370
1700*3000	639	191	405	830	263	436
2000*3500	875	308	590	1138	424	632
2500*4000	1381	663	1050	1815	925	1110
2500*5500	2019	943	1333	2653	1317	1410
3000*5000	2104	1210	1880	2709	1571	2155
3000*6000	2583	1485	2160	3292	1888	2470
3300*4500	1884	1175	2020	2476	1640	2300
3300*6500	3015	1814	2700	3961	2532	3080
