CCS BV Approved Pneumatic Fenders

CCS BV Approved Pneumatic Fenders thumbnail-1
CCS BV Approved Pneumatic Fenders photo-1
US$ 6,000 - 10,000 MOQ: 4 Sets
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Florescence
Model Number:
D2.5*L4.5m designed to demand
Contact Supplier Request Quote Chat Now
Qingdao Florescence Rubber Products Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name Florescence
Model Number D2.5*L4.5m designed to demand
Part Other, Chain and tire net

Specifications

pneumatic fenders
1.Material:54% natural rubber
2.Service life10years
3.CCS ,BV approved
4.Good tightness

Florescence Floating Pneumatic Rubber Fender --- On-Time, On-Budget&On-Spec

Yokohama Pneumatic Rubber Fenders have been widely used for berthing structures as well as in ship-to-ship

services since 1958. Due to its superior performance, major industries such as oil, mineral ore, offshore

construction and drilling, fishing and shipbuilding, as well as port authorities and navies all over the world adopt it.

We produce strictly comply with ISO 17357 and has been a pneuamtic fenders supplier for Chinese and Italian Navy!



Key Attributes:

Ease of handling and good buoyancy

Low surface pressure with low reaction and High Energy Absorption Rate

Easy installation & maintenance free

Exceptional Compressibility and elasticity

Purpose apt with the Large and small tides

Pneumatic fenders facilitate large stand-off



Range:
Florescence Pneumatic Fenders are available in wide range from 500mm diameter to 4500mm diameter in 1000mm

length to 12000mm length as per specified requirements.



Applications:

Ship to ship transfers atseas.

Double banking operation as well as vessel to berth at dock/jetty.

Oil & gas tankers

Fast ferries & aluminum vessels

Temporary and permanent installations

Rapid response and emergencies

Liquid cargo and naval defense vessels

CCS BV approved pneumatic fenders

CCS BV approved pneumatic fenders

Technical parameters of fenders :

D: 0.5-4.5meters L: 1.0-12meters

Can be supplied customized size upon customers' request.

Specifications

D*L(m)









Initial pneumatic pressure 0.05MPa

Initial pneumatic pressure 0.05MPa



Applicable ships tonnage

(T)



Remark





Sphere

Weight

(kg)



R(KN)









GEA(KG)









Sphere

Weight

(kg)



R(KN)





GEA(KG)





0.5*1.0

25

64

6

25

83

8

50

Fishing ship

0.6*1.0

32

74

8

32

96

11

50

Fishing ship

0.7*1.0

50

137

17

50

178

24

100

Fishing ship

1.0*1.5

80

182

32

80

235

44

100

Fishing ship

1.0*2.0

100

257

45

125

335

63

200

Fishing ship, Tugboat

1.2*2.0

120

297

63

165

386

86

300-500

Fishing ship, Tugboat

1.35*2.5

165

427

102

226

554

140

300-500

Fishing ship, Tugboat

1.5*3.0

315

597

153

370

751

211

1000

Tugboat,Transportation ships

1.7*3.0

405

639

191

436

830

263

1000

Deep sea trawling ships,Transportation ships

2.0*3.5

590

875

308

632

1138

424

3000

Deep sea trawling ships,Transportation ships

2.5*4.0

1050

1381

663

1110

1815

925

10000

Transportation ships

2.5*5.5

1333

2019

943

1410

2653

1317

10000

Transportation ships

3.0*5.0

1880

2104

1210

2155

2709

1571

10000above

Transportation ships

3.0*6.0

2160

2583

1485

2470

3292

1888

10000above

Transportation ships

3.3*4.5

2020

1884

1175

2300

2476

1640

10000above

Transportation ships

3.3*6.0



2300

2783

1675

2600

3652

2338

10000above

Transportation ships

3.3*6.5

2700

3015

1814

3080

3961

2532

10000above

Transportation ships

CCS BV approved pneumatic fenders

CCS BV approved pneumatic fenders
