Specifications
puter controltal plate box frame type structure
3.high speed ,constant linear speed ,low noise ,large package
Computer numerical control composite twisting machine
JC2005 type computer numerical control of composite twisting machine factory is the development and production of the JC2002 series of one step twisting of the new generation of products ,the machine has advantages of type 2000 twisting machine .
specification
| Type | Double-faced double-cleck dragon belt | |
| Spindle speed | 2000-7000 RPM(according to different yarn) | |
| Numble of spindles |
420 pounds(upper) 140 pounds(lower) |
588 pounds(upper) 196 pounds(lower) |
|
540 pounds(upper) 180 pounds(lower) |
630 pounds(upper) 210 pounds(lower) |
|
| Spindle pitch | 162mm | |
| Twist range | 60-1000 twist per meter | |
| Twist | Computer control filament twist is S to Z could be | |
| Computer control for Z to S can be twisted to | ||
| The inner diameter of steel |
ø 98mm, ø115mm, ø125mm, ø133mm, ø140mm, ø150mm |
|
| Lift | Computer control of 50-330mm | |
| Forming mode | Computer control of molding | |
| Doublings | 2 ply,3ply,4ply | |
| Motor power |
Roller 2.2KW,Forming 1.5KW, Main motor 11KW,15KW,18.5KW |
|
| Maximum roll weight | 1kg ,1.5kg ,2 kg | |
| Machine size |
According to the different models and distribution,according to the fixed length of yarn roving machine: 21000mm X (800)1200mm X 1800mm 16800mm X (800)1200mm X 1800mm 20000mm X (800)1200mm X 1800mm |
|
| Roller | Light roller,a capstan roller | |
| The whole machine weight | About 7.5T-8T | |
sample machine
The upper two monofilaments first twist ,the lower second twisting into strands ;the upper three monofilaments first twist ,the lower second twisting strands wire .The maximum volume device of 1 kg ,1.5 kg ,2 kg .
Packaging detail : yarn twisting machine is wooden packing for exporting
Deliverry detail : within 20-30 days when receiving the TT advance or L/C at sight
1.Installation Services
Installation Services are available with all new machine purchases. We will provide the technical know-how for your operation smooth transition and support for installing, debugging, operation of the machine, it will indicate you how to use this machine well.
2.Clients Traning Services
We can train your staff to use your equipment systems properly.It means that we offer Customers Training, teaching how to use the systems most efficiently and safely as well as how to maintain optimal operational productivity.
3.Good After-Sales Service
We offer the Preventative Maintenance and After Sales Service.We offer comprehensive maintenance options to prevent equipment issues before they become problems. Also we offer one year guarantee period.
