Water Filter 4 Inch Cutting Disc Filter Mesh

Water Filter 4 Inch Cutting Disc Filter Mesh thumbnail-1
Water Filter 4 Inch Cutting Disc Filter Mesh thumbnail-2
Water Filter 4 Inch Cutting Disc Filter Mesh thumbnail-3
Water Filter 4 Inch Cutting Disc Filter Mesh thumbnail-4
Water Filter 4 Inch Cutting Disc Filter Mesh thumbnail-5
Water Filter 4 Inch Cutting Disc Filter Mesh thumbnail-6
Water Filter 4 Inch Cutting Disc Filter Mesh photo-1
Water Filter 4 Inch Cutting Disc Filter Mesh photo-2
Water Filter 4 Inch Cutting Disc Filter Mesh photo-3
Water Filter 4 Inch Cutting Disc Filter Mesh photo-4
Water Filter 4 Inch Cutting Disc Filter Mesh photo-5
Water Filter 4 Inch Cutting Disc Filter Mesh photo-6
US$ 0.1 - 5 MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
Shangshai
Model Number:
JPP water filter 4 inch cutting disc filter mesh
Contact Supplier Request Quote Chat Now
Shanghai Shangshai Bolting Cloth Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shangahi
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name Shangshai
Model Number JPP water filter 4 inch cutting disc filter mesh
Usage Solid Filter
Type Other, Filter Elements, water filter 4 inch cutting disc filter mesh
Material Nylon
Hole Shape Square
Filter Rating 30-1500um
Thickness 80-1000um
Length 30-70m/roll
Width 115-365cm water filter 4 inch cutting disc filter mesh

water filter 4 inch cutting disc filter mesh

Product Overviews

General introduction of our company(factory)

We,Shanghai Shangshai Bolting Cloth Manufacturing Co.,Ltd,specialized in nylon screen mesh fabric for more than 15 years,exporting nylon mesh filter with high quality and competitive price.Hope to be a partner with you.

water filter 4 inch cutting disc filter mesh

Specifications of water filter 4 inch cutting disc filter mesh:

1)Material: 100% nylon

2)Weaving: Plain weave

3)Mesh Count: 4T~140T mesh/cm(13mesh~355 mesh/inch)
4)Max. Width: 365cm (143 inch)
5)Color: White(Customized)

6)Mesh Opening:30-1500um

7)Color: white/yellow/orange

8)Packing: PVC bag inside for each roll, then carton,then waterproof bag outside

Features & advantages of water filter 4 inch cutting disc filter mesh:

1. Faster turnaround time from the screen room to the pressroom
2. Good diathermancy
3. High air permeability
4. Acid resistance and Alkali resistance
5. Long working life
6. Hard wear
7. Three factories for manufacturing
8. Imported weaving machines from Switzerland and Italy



Applications of water filter 4 inch cutting disc filter mesh:
Filteration: Widely used in areas as filtration and separation industry. Such as food industry for milling filtering and flour milling, milling and other grains milling. Like glucose production, milk powder, soybean milk etc.





Technical specifications of nylon filter mesh:

white polyamide bolting cloth
   Model  mesh
 count
 (/cm)		 mesh
count
(/inch)		   thread
diameter
(um)		   mesh
opening
(um)		 open
area
(%)		 thickness
(um)		 weight
( g/ m2 )
NL4/1931 4 10 550 1931  60  1100  251
NL5/1485 5 13 500 1485  55  1000  270
NL5/1535 5 13 450 1535  59  900  218
NL6/1254 6 15 400 1254  57  800  199
NL7/1068 7 18 350 1068  56  700  183
NL8/891 8 20 350 891  51  700  203
NL8/990 8 20 250 990  63  500  104
NL9/853 9 24 250 853  59  500  125
NL10/743 10 25 250 743  55  500  130
NL10/693 10 25 300 693  48  600  187
NL12/578 12 30 250 578  48  500  156
NL12/528 12 30 300 528  40  600  224
NL14/410 14 35 300 410  33  510  261
NL14/509 14 35 200 509  51  340  116
NL16/421 16 41 200 421  45  340  136
NL16/371 16 41 250 371  35  425  213
NL17/384 17 42 200 384  43  340  139
NL18/332 18 45 220 332  36  374  181
NL20/347 20 50 150 347  48  255  93
NL20/297 20 50 200 297  35  340  166
NL24/264 24 60 150 264  40  255  112
NL28/235 28 70 120 235  43  204  84
NL28/205 28 70 150 205  33  255  131
NL30/211 30 76 120 211  40  204  91
NL32/210 32 80 100 210  45  170  66
NL36/176 36 90 100 176  40  170  75
NL40/149 40 100 100 149  35  170  83
NL44/126 44 110 100 126  31  170  91
NL43/151 43 110 80 151  42  136  58
NL48/127 48 120 80 127  37  136  64
NL56/117 56 142 60 117  43  102  42
NL59/108 59 150 60 108  41  102  45
NL64/95 64 163 60 95  37  102  49
NL72/88 72 183 50 88  40  85  38
NL76/79 76 193 52 79  36  88  43
NL80/74 80 203 50 74  35  85  42
NL88/71 88 224 42 71  39  71  33
NL96/62 96 244 42 62  35  76  36
NL100/55 100 254 42 55  31  80  37
NL104/51 104 264  42 51  29  71  39
NL110/46 110 279  42 46  25  76  41
NL120/39 120 305  42 39  21  80  45
NL120/43 120 305  38 43  25  65  37
NL120/46 120 305  35 46  29  60  31
NL130/32 130 330  43 32  17  73  51
NL130/40 130 330  35 40  25  60  34
NL140/35 140 356  35 35  22  60  36
NL150/34 150 381  31 34  25  53  30

Remark:The above are theoretic data for reference only.Thickness error range±5% ;

Mesh Opening & Open Area & Weight only slight error according to actual data.



Production Flow

water filter 4 inch cutting disc filter mesh

OEM Service

Application of water filter 4 inch cutting disc filter mesh :

It is widely used in home electronics, industries of petroleum, industry products,chemical, medic fields,water and air filtration,metallurgy, environmental dedusting and mine. The fabric has been brushed, so it is more flexible and thicker,the dedusting efficiency can reach 99.99%.

water filter 4 inch cutting disc filter mesh

water filter 4 inch cutting disc filter mesh

1. Why should I choose ShangShai Bolting Cloth ?
ShangShai provides customers with the very fine quality nylon mesh. We havemore than 300sets of Sulzer weaving machines to make sure the shortest lead time.Also factory equipped with someGemany−imported machines. The strict quality management system enables ShangShai Bolting Cloth advantages,such as improved fabric strength & tension  stabilization compared to other manufactures.

2.Can I get a discount ?
As you know that, we win the market with competitive price and good quality. So, the price we given are always the best. But we can give you a special discount if your order quantity is attractive.
3. How do you settle problems if the goods have problems and cannot use?
We promise you that the goods can be compensated and returned if you are not satisfied with the quality.
4. My order quantity is small,can you provide?
Yes.We will serve every customer with good quality products and services no matter how much your order is.

5.Can you receive OEM service?
Yes. We provide OEM services for customers.Round Pieces,square pieces,ribbons types,small width rolls.Different shape and width can be offered.
