teflon coated conveyor belt with bull nose size 4mm x4mm high temperature resistance
1,Thebrief introduction of teflon coated conveyor belt with bull nose size 4mm x4mm high temperature resistance :
- teflon mesh conveyor belt define specifications by size.
- According to the different warp and weft, divided into single and double weft weft teflon mesh cloth.
2,The felture of teflon coated conveyor belt with bull nose size 4mm x4mm high temperature resistance :
- Resistance to high and low temperature to 70 °C to 260 °C.The climate resistance, anti-aging, long use period
- Resistance to sticky, easy to clean up
- resistance All kinds of strong acid and alkali corrosion , resistance to chemical medicinal, non-toxic
- Dimension stability, extension coefficient is less than 5 %, high strength, good mechanical properties.
- Resistance to bending fatigue, can be used for small wheel diameter.
3,The aplication of teflon coated conveyor belt with bull nose size 4mm x4mm high temperature resistance :
- Drying of textile printing and dyeing, printing conduction band, screen printing, UV drying, UV series, light solid machine, offset press
- Pine dryer, non-woven drying machine, high frequency dryer, food baking machine conduction band, temperature control chamber
- Solvent based ink rapid drying and general water of items such as drying equipment.
- teflon mesh conveyor belt is widely applied in fusing machine, garment printing and dyeing machinery
4, The Commonly used specifications of teflon coated conveyor belt with bull nose size 4mm x4mm high temperature resistance :
| model | Apertre | material | thickness | weight /g | temperature | Max width | strenth(N/cm) | ||
| W-O5J | 1x 1mm | Glass fiber | 0.5mm | 370g /m 2 | -70 -260 °C | 4m |
|
||
| W-07J | 2x 2mm | Glass fiber | 0.7mm | 450g /m 2 | -70 -260 °C | 4m |
|
||
| W-1J | 4x 4mm | Glass fiber | 1.0mm | 400g /m 2 | -70 -260 °C | 4m |
|
||
| W-2J | 4x 4mm | Glass fiber | 1.0mm | 450g /m 2 | -70 -260 °C | 4m |
|
||
| W-12KJ | 4x 4mm | Glass fiber | 1.2mm | 600g /m 2 | -70 -260 °C | 4m |
|
||
| W-3J | 4x 4mm | Glass fiber | 1.0mm | 500g /m 2 | -70 -260 °C | 4m |
|
||
| W-4J | 4x 4mm | Glass fiber | 1.0mm | 500g /m 2 | -70 -260 °C | 4m |
|
||
| W-5J | 4x 4mm | Glass fiber | 1.0mm | 550g /m 2 | -70 -260 °C | 4m |
|
||
| W-12J | 10x 10mm | Glass fiber | 1.2mm | 450g /m 2 | -70 -260 °C | 4m |
|
||
| NW-14J | 0.5x 1mm | Glass fiber | 0.5mm | 420g /m 2 | -70 -260 °C | 4m | 310/290 N/cm | ||
| W-09J | 2x 2.5mm | Glass fiber | 0.9mm | 600g /m 2 | -70 -260 °C | 3m |
|
5,The pictures of teflon coated conveyor belt with bull nose size 4mm x4mm high temperature resistance :
6,Scan the qr code below to contact us, we will wholeheartedly for your service!
More variety, better quality, better price, look forward to your contact!
