Teflon Conveyor Belt Manufacturer Good Quality Different Mesh Size
US$ 5.7 - 36.7
MOQ: 10 Square Meters
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
PFM
Model Number:
EIL-TC
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Plastic Mesh/Plastic Breeding Net/Plastic Flat Mesh(manufactory)US$ 0.2 - 2.5MOQ: 1000 Square Meters -
Reinforcement Concrete Fiberglass MeshUS$ 0.12 - 0.35MOQ: 100 Meters
-
Blade Barbed Wire Mesh Fence ManufactoryUS$ 1 - 999MOQ: 1 Roll
-
Sewage Treatment High Tensile Extruded Plastic MeshUS$ 0.2 - 2.5MOQ: 1000 Square Meters
-
Hot Sale Good Material and Long Working Life Teflon Conveyor BeltUS$ 5.7 - 36.7MOQ: 10 Square Meters
Place of Origin
Hebei, China
Brand Name
PFM
Model Number
EIL-TC
Specifications
teflon conveyor belt manufacturer good quality different mesh sizeResistance to high and low temperature -70to 260
teflon conveyor belt manufacturer good quality different mesh size
1,Thebrief introduction of teflon conveyor belt manufacturer good quality different mesh size :
- teflon mesh conveyor belt define specifications by size.
- According to the different warp and weft, divided into single and double weft weft teflon mesh cloth.
2,The felture of teflon conveyor belt manufacturer good quality different mesh size :
- Resistance to high and low temperature to 70 °C to 260 °C.The climate resistance, anti-aging, long use period
- Resistance to sticky, easy to clean up
- resistance All kinds of strong acid and alkali corrosion , resistance to chemical medicinal, non-toxic
- Dimension stability, extension coefficient is less than 5 %, high strength, good mechanical properties.
- Resistance to bending fatigue, can be used for small wheel diameter.
3,The aplication of teflon conveyor belt manufacturer good quality different mesh size :
- Drying of textile printing and dyeing, printing conduction band, screen printing, UV drying, UV series, light solid machine, offset press
- Pine dryer, non-woven drying machine, high frequency dryer, food baking machine conduction band, temperature control chamber
- Solvent based ink rapid drying and general water of items such as drying equipment.
- teflon mesh conveyor belt is widely applied in fusing machine, garment printing and dyeing machinery
4, The Commonly used specifications of teflon conveyor belt manufacturer good quality different mesh size :
| model | Apertre | material | thickness | weight /g | temperature | Max width | strenth(N/cm) | ||
| W-O5J | 1x 1mm | Glass fiber | 0.5mm | 370g /m 2 | -70 -260 °C | 4m |
|
||
| W-07J | 2x 2mm | Glass fiber | 0.7mm | 450g /m 2 | -70 -260 °C | 4m |
|
||
| W-1J | 4x 4mm | Glass fiber | 1.0mm | 400g /m 2 | -70 -260 °C | 4m |
|
||
| W-2J | 4x 4mm | Glass fiber | 1.0mm | 450g /m 2 | -70 -260 °C | 4m |
|
||
| W-12KJ | 4x 4mm | Glass fiber | 1.2mm | 600g /m 2 | -70 -260 °C | 4m |
|
||
| W-3J | 4x 4mm | Glass fiber | 1.0mm | 500g /m 2 | -70 -260 °C | 4m |
|
||
| W-4J | 4x 4mm | Glass fiber | 1.0mm | 500g /m 2 | -70 -260 °C | 4m |
|
||
| W-5J | 4x 4mm | Glass fiber | 1.0mm | 550g /m 2 | -70 -260 °C | 4m |
|
||
| W-12J | 10x 10mm | Glass fiber | 1.2mm | 450g /m 2 | -70 -260 °C | 4m |
|
||
| NW-14J | 0.5x 1mm | Glass fiber | 0.5mm | 420g /m 2 | -70 -260 °C | 4m | 310/290 N/cm | ||
| W-09J | 2x 2.5mm | Glass fiber | 0.9mm | 600g /m 2 | -70 -260 °C | 3m |
|
5,The pictures of teflon conveyor belt manufacturer good quality different mesh size :
6,Scan the qr code below to contact us, we will wholeheartedly for your service!
More variety, better quality, better price, look forward to your contact!
