Specifications
Polyester Spiral Press Filter BeltEasy installation
Without trace
Strength can reach 100%
long working lifespan
Polyester Spiral Press Filter Belt
Polyester spiral press filter belts are heat-set at exacting temperature and tension to give maximum operation stability. It is designed for use in solid/liquid separation, as well as sludge dewatering for vacuum and multi-roll belt presses. The unique spiral weave patterns offer rapid drainage and outstanding cake release.
PFM polyester spiral press filter belt offers the following advantages:
- Acidic resistance,
- Alkaline resistance,
- Corrosion resistance
- Temperature resistant
- A long lifespan of using.
- Stronger than common carpet and cavas
- Smooth surface of mesh,
- Strong bursting strength,
- Good permeability,
- Excellent conduct electricity and saving energy.
- Easy installation and without trace,
- Strength can reach 100% compare with general mesh.
Technical Index of polyester spiral press filter belt:
Weaving Type |
Model |
Thread Diameter (mm) |
Air permeability |
||
Warp |
Weft |
filled with stuff |
|||
Large Loop |
4070 |
0.9 |
1.1 |
0.9×4 |
5500±500 |
0.9×5 |
4500±500 |
||||
Medium Loop |
3868 |
0.7 |
0.9 |
0.8×3 |
4750±500 |
0.8×4 |
4200±500 |
||||
Small Loop |
3252 |
0.52 |
0.7 |
0.68×3 |
15000±500 |
Typical Applications of polyester spiral press filter belt are:
A long experience in the field of industrial fabrics and a constant attention to ecology have allowed PFM to develop a wide range of polyester spiral press filter belts for mechanical dewatering of liquid to solid for any kind of material.
- Our product range covers all sludge belt press liquid filtration applications, such as:
- Dewatering of inert sludge from quarries or mines
- Dewatering of biological or chemical sludge from municipality sewage plants
- Pressing of grapes, fruit and others
