Home > Industrial Equipment & Components > Ventilation Equipment > Ventilation Fan > CSZ Marine Water Power Axial Fan

CSZ Marine Water Power Axial Fan

Name: CSZ Marine Water Power Axial Fan
Brand: Jinbo
SKU: 139632161
Availability: InStock

CSZ Marine Water Power Axial Fan thumbnail-1

CSZ Marine Water Power Axial Fan photo-1

US$ 100 - 1,000 MOQ: 1 Piece

Key Specifications

Get Latest Price

Electric Current Type:

Other, NO ELECTRIC POWER

Mounting:

Duct Fan

Blade Material:

Other, Copper

Contact Supplier Request Quote Chat Now

Chongqing Jinbo Marine Equipment Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Electric Current Type Other, NO ELECTRIC POWER

Mounting Duct Fan

Blade Material Other, Copper

Place of Origin Shandong, China

Brand Name Jinbo

Model Number CSZ-300/CSZ-380

Power 0.15~110KW

Air Volume 3000~10000m3/h

Certification Other, CCS/ABS/RINA/RS/BV/DNV/LR/GL/VR etc

After-sales Service Provided Engineers available to service machinery overseas

CSZ Marine Water Power Axial Fan:

General:

CSZ series marine water power axial fan has the high explosion proof glass, anti-corrosion, swing resistance, shock resistance. The structure is simple, compact. The weight is light, the operation is easy.Normally only one operator is required. It is directly driven by the fire fighting water, no need for other power equipment.It can deliver the flammable and explosive gas, steam and other dangerous & poisonous gas.

Structure:

The fan is composed of water turbine, casing, frame,rotor and impellers. The water turbine is casting by anti-corrosive copper alloy, the casing is welded by the stainless steel. The water turbine and the rotor adopt two grades of sealing, mechanical seal and packing seal. A safe brass ring fitted between the casing and the impellers,so that it is without spark structure..

CSZ fan serve as supply fan or exhaust fan, but they can not displace the function.

Applicable Conditions:

The places where there are explosive grad IIB & IIC and group from T4 to T6.

Ambient temperature: -25 centigrade degree to 55 centigrade degree

Relative humidity of the air: not over 95%

Cyclical vacillation:+-22.5 degree

Sustained horizontal tilting: +-15 degree

Sustained vertical tilting:+-10 degree

Main Parameter:

Model	Flow rate	Static pressure	Water pressure	Water consumption	D1	D2	D3	D4	H	n-d	Weight
Model	m3/h	Pa	Mpa	m3/h	D1	D2	D3	D4	H	n-d	kgs
CSZ-300	3000-6000	260-820	0.2-0.5	25-43	300	336	366	446	404	8-D11	30.5
CSZ-380	4000-10000	380-1020	0.2-0.5	28-53	380	416	446	546	546	8-D11	35
