Help CenterExplosion-proof Oil Content Meter
US$ 1,300 - 1,600
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
jinbo
Model Number:
CY-2
Power:
Electronic
Payment & Shipping
Payment Methods:
Port of Shipment:
China Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
M Series Positive Displacement Flow MeterUS$ 1,200 - 4,500MOQ: 1 Unit -
Digital Anemometer SystemUS$ 1,000 - 4,000MOQ: 1 Unit
-
Marine Wall-Mounted Master Cock CJCZ-2MUS$ 1,000 - 5,000MOQ: 10 Pieces
-
Marine Embedded Intelligent Master Cock CJCZ-2M QUS$ 1,000 - 5,000MOQ: 10 Pieces
-
Marine Intelligent Master Cock CJCZ-3MUS$ 1,000 - 5,000MOQ: 10 Pieces
Brand Name
jinbo
Model Number
CY-2
Power
Electronic
Usage
Other, Oil Content Meter
OCD1A Explosion-proof oil content meter is an online testing instrument for micro oil content in waste water.It's used in the circustances of explosion-proof,such as sites concerning petrochemical waste water continually,build up alarm reporting for over-limitation and control the volume of discharge waste water.
Technical Specification
| Testing Type | Continuously online testing |
| Measurement range | 0~199ppm |
| Precision | 0-20 ppm±2ppm,20-199ppm±10% |
| Alarm indication | Red LED |
| Pressure of sample water | 0.01~0.6Mpa |
| Flow rate | 0.15-4L/min |
| Working voltage | 220VAC,50/60Hz |
| Power | 25W |
| Signal output | 4~20Ma or 0~5VDC |
| Water-proof protection | IP45 |
| Mounting dimension | 420×210mm |
| Boundary dimension | 460×300×184mm |
| Weight | 28KG |
